Snap Ring Groove Ball Bearings 6408 N

The 6408 N is a snap ring groove ball bearing with a 40mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 14320 lbf and operates smoothly at speeds up to 9000 RPM.

Its open design and stainless steel cage ensure durability, while the snap ring groove on the outer ring provides secure mounting. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads and easy installation are key.

Weighing 1.26kg, it offers a robust build for its size. Compliant with REACH standards for safe use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6408 N
Brand TFL
Interchangeable SKF
Bore Dia 40 mm
Bore Dia Tolerance -0.01mm to 0
Outer Dia 110 mm
Outer Dia Tolerance -0.013mm to 0
Width 27 mm
Width Tolerance -0.12mm to 0
Outside Diameter Of Snap Ring 110 mm
Width Of Snap Ring 2.7 mm
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Open
Locating Feature Bearing Outer Ring Snap Ring Groove
Tolerance Class P6
Radial Clearance Trade No CN
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Stainless Steel
Dynamic Radial Load 14320 lbf
Static Radial Load 8206 lbf
Temperature Range -30° to 120 °C
REACH Compliant
Max Speed 9000 rpm
Weight 1.26 kg

Snap Ring Groove Ball Bearings 6408 N dimension drawing

Download DWG Download PDF

Features

Performance Features of 6408 N Bearing

6408 N Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 14320 lbf, making it suitable for demanding applications.

The stainless steel cage ensures smooth operation by keeping the balls properly aligned.
With a maximum speed of 9,000 rpm, it balances performance and durability.

6408 N Bearing’s snap ring groove design simplifies installation and enhances stability.
It operates efficiently in temperatures ranging from -30° to 120°C.

The precision-engineered dimensions (40 mm×110 mm×27 mm) ensure a perfect fit.
Its open seal type allows for easy maintenance and lubrication.

Application

Industrial Uses of 6408 N Bearing
The 6408 N Bearing is commonly used in heavy machinery like conveyor belts and gearboxes, where its snap ring groove ensures secure mounting. Its chrome steel construction offers durability in high-load environments.

Where Is 6408 N Bearing Used?
You’ll often find the 6408 N Bearing in automotive applications such as wheel hubs and transmissions, thanks to its reliable radial load capacity. The open design allows for easy lubrication, extending its service life.

Built for Heavy-Duty Use: 6408 N Bearing
In industrial settings, the 6408 N Bearing handles demanding tasks like pump systems and electric motors. Its stainless steel cage reduces wear, making it a dependable choice for continuous operation.

Automotive vs Industrial: Applications of 6408 N Bearing
The 6408 N Bearing excels in both automotive and industrial sectors, supporting everything from vehicle drivetrains to factory equipment. Its metric sizing ensures compatibility with a wide range of machinery.

Perfect Fit for Automation: 6408 N Bearing
For robotic arms and automated assembly lines, the 6408 N Bearing provides smooth, precise movement. Its snap ring groove design simplifies installation, saving time during maintenance.
