Snap Ring Groove Ball Bearings 6308N/C3

Snap Ring Groove Ball Bearings 6308N/C3

The 6308N/C3 is a snap ring groove ball bearing with a 40mm bore and 90mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 915 lbf and operates smoothly at speeds up to 7500 RPM.

Its open design and snap ring groove on the outer ring make installation and positioning straightforward. The C3 radial clearance ensures reliable performance under varying temperatures, from -30°C to 120°C.

This bearing is interchangeable with SKF models, offering a practical replacement option. It’s well-suited for machinery where secure mounting is needed, such as pumps or electric motors.

Compliant with RoHS and REACH standards, it’s a safe and durable choice for industrial applications. The lightweight design adds to its versatility.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6308N/C3
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012 mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015 mm to 0
  • Width 23 mm
  • Width Tolerance -0.12 mm to 0
  • Outside Diameter Of Snap Ring 90 mm
  • Width Of Snap Ring 2.7 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Locating Feature Bearing Outer Ring Snap Ring Groove
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 915 lbf
  • Static Radial Load 5395 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 7500 rpm
  • Price（$） 9.64
Snap Ring Groove Ball Bearings 6308N/C3 dimension drawing
Download DWG Download PDF

Features

How Does 6308N/C3 Bearing Reduce Friction?

6308N/C3 Bearing features chrome steel rings and balls, ensuring smooth operation with minimal friction.
The snap ring groove design provides secure mounting, enhancing stability during high-speed rotation.

With a dynamic radial load capacity of 915 lbf, it handles demanding radial loads efficiently.
Its open design allows for easy lubrication, reducing wear and extending service life.

The C3 radial clearance ensures optimal performance under varying thermal conditions.
This makes 6308N/C3 Bearing suitable for a wide range of industrial applications.

Application

Industrial Uses of 6308N/C3 Bearing
The 6308N/C3 Bearing is commonly used in industrial machinery like pumps and gearboxes, where its snap ring groove ensures secure outer ring positioning. Its open design allows for easy lubrication, extending service life in demanding environments.

In automotive applications, 6308N/C3 Bearing fits well in wheel hubs and transmission systems, handling radial loads efficiently. The C3 clearance provides flexibility for thermal expansion, making it suitable for varying operating temperatures.

For automation equipment, 6308N/C3 Bearing’s chrome steel construction offers reliable performance in robotic arms and conveyor systems. The snap ring feature simplifies installation, reducing downtime during maintenance.

Where Is 6308N/C3 Bearing Used?
You’ll find 6308N/C3 Bearing in household appliances like washing machines, where its durability handles constant rotation. The metric sizing ensures compatibility with a wide range of European-designed products.

Built for Heavy-Duty Use: 6308N/C3 Bearing
In agricultural machinery, 6308N/C3 Bearing withstands dusty conditions while maintaining smooth operation. Its robust design makes it a go-to choice for equipment like harvesters and tractors.
