Snap Ring Groove Ball Bearings 6305 N

Snap Ring Groove Ball Bearings 6305 N

The 6305 N is a snap ring groove ball bearing with a 25mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 5261 lbf and operates smoothly at speeds reaching 16,000 RPM.

Its open design and stainless steel cage ensure durability, while the snap ring groove on the outer ring provides secure mounting. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads and secure positioning are key.

Weighing 0.22kg, it’s a compact yet robust option. Compliant with REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6305 N
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • Outside Diameter Of Snap Ring 62 mm
  • Width Of Snap Ring 1.9 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Locating Feature Bearing Outer Ring Snap Ring Groove
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 5261 lbf
  • Static Radial Load 2608 lbf
  • Temperature Range -30° to 120 °C
  • REACH Compliant
  • Max Speed 16000 rpm
  • Weight 0.22 kg
Snap Ring Groove Ball Bearings 6305 N dimension drawing
Download DWG Download PDF

Features

How Does 6305 N Bearing Reduce Friction?

6305 N Bearing features chrome steel rings and balls, ensuring smooth operation with minimal friction.
Its single-row design and snap ring groove provide stability, making it suitable for radial loads.
The stainless steel cage maintains ball alignment, reducing wear and extending service life.
With a maximum speed of 16,000 rpm, it delivers reliable performance in various applications.

Why Choose 6305 N Bearing for Precision Tasks?

6305 N Bearing is precision-engineered with a P6 tolerance class, ensuring accurate performance.
The chrome steel construction resists wear, maintaining smooth operation over time.
Its snap ring groove design simplifies installation, saving time and effort.
With a dynamic radial load capacity of 5261 lbf, it handles demanding tasks with ease.

Built for Reliability: 6305 N Bearing

6305 N Bearing’s chrome steel components provide durability and long-lasting performance.
The open design allows for easy lubrication, reducing maintenance needs.
Its snap ring groove ensures secure positioning, enhancing operational stability.
With a temperature range of -30° to 120°C, it performs well in various environments.

Application

Common Applications of 6305 N Bearing
The 6305 N Bearing is widely used in industrial machinery, such as pumps and electric motors, where its snap ring groove ensures secure mounting. Its open design allows for easy lubrication, extending service life in demanding conditions.

In automotive applications, 6305 N Bearing fits well in gearboxes and wheel hubs, providing reliable radial load support. The P6 tolerance class ensures precise operation, even under high-speed conditions.

For automation systems, 6305 N Bearing’s stainless steel cage offers durability in robotic arms and conveyor belts. Its metric sizing makes it compatible with a variety of European and Asian equipment standards.

Where Is 6305 N Bearing Used?
You’ll often find 6305 N Bearing in household appliances like washing machines, where its radial load capacity handles constant motion. The chrome steel construction resists wear, ensuring long-term performance.

In agricultural machinery, 6305 N Bearing supports components like harvesters and tractors. Its snap ring groove design simplifies installation, reducing maintenance downtime in rugged environments.

Built for Heavy-Duty Use: 6305 N Bearing
The 6305 N Bearing excels in construction equipment, such as cranes and excavators, thanks to its high dynamic radial load rating. Its temperature range also makes it suitable for outdoor use in varying climates.

For food processing machinery, 6305 N Bearing’s open design allows for easy cleaning, meeting hygiene standards. The stainless steel cage further enhances corrosion resistance in wet environments.

Automotive vs Industrial: Applications of 6305 N Bearing
In automotive transmissions, 6305 N Bearing handles high-speed rotations with minimal friction. Its snap ring groove ensures stability, even under constant vibration.

For industrial fans, 6305 N Bearing’s robust design supports continuous operation. The P6 tolerance class ensures smooth performance, reducing energy consumption over time.
