Single Row Deep Groove Ball Bearings 6314-2Z

Single Row Deep Groove Ball Bearings 6314-2Z

The 6314-2Z is a single-row deep groove ball bearing with a 70mm bore and 150mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 24954 lbf and operates smoothly at speeds up to 5000 RPM.

Shielded on both sides, it keeps grease in and dirt out, making it low-maintenance. The stainless steel cage adds durability, while the P6 tolerance ensures precise performance.

This bearing suits a wide temperature range, from -30°C to 120°C, and is interchangeable with SKF models. Ideal for electric motors or pumps where reliability is key.

Weighing 2.65kg, it’s a robust choice for industrial applications. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6314-2Z
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 35 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 24954 lbf
  • Static Radial Load 15287 lbf
  • Max Speed 5000 rpm
  • Weight 2.65 kg
  • price（$） 45.873
Single Row Deep Groove Ball Bearings 6314-2Z dimension drawing
Download DWG Download PDF

Features

How Does 6314-2Z Bearing Reduce Friction?

6314-2Z Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
The chrome steel construction ensures durability while maintaining low friction during operation.

Its shielded design protects against contaminants, enhancing performance in various environments.
With a dynamic radial load capacity of 24,954 lbf, it handles demanding applications reliably.

The stainless steel cage keeps the balls aligned, reducing wear and extending service life.
Operating at up to 5,000 rpm, it balances efficiency and longevity for industrial use.

Application

Industrial Uses of 6314-2Z Bearing
6314-2Z Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability even in demanding environments.

Where Is 6314-2Z Bearing Used?
You’ll often find 6314-2Z Bearing in automotive applications such as wheel hubs and transmissions, thanks to its ability to handle radial loads smoothly. Its grease lubrication also reduces maintenance needs over time.

Built for Heavy-Duty Use: 6314-2Z Bearing
6314-2Z Bearing works well in conveyor systems and gearboxes, where its high dynamic radial load capacity is a real advantage. The stainless steel cage adds extra resilience for long-term performance.

Automotive vs Industrial: Applications of 6314-2Z Bearing
In cars, 6314-2Z Bearing supports wheel assemblies, while in factories, it’s a go-to for machinery requiring reliable radial load support. The P6 tolerance class ensures precision in both settings.

Perfect Fit for Automation: 6314-2Z Bearing
6314-2Z Bearing is a solid choice for robotic arms and automated systems, where smooth operation is key. Its temperature range makes it suitable for various working conditions.
