Single Row Deep Groove Ball Bearings 6304 DFGA

Single Row Deep Groove Ball Bearings 6304 DFGA

The 6304 DFGA is a single row deep groove ball bearing with a 20mm bore and 52mm outer diameter, crafted from sturdy chrome steel for durability. It manages radial loads up to 3574 lbf and operates smoothly at speeds up to 14,000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures reliable performance under stress. The bearing functions well in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing just 144g, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6304 DFGA
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3574 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 14000 rpm
  • Weight 144 g
Single Row Deep Groove Ball Bearings 6304 DFGA dimension drawing
Download DWG Download PDF

Features

Performance Features of 6304 DFGA Bearing

6304 DFGA Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 3574 lbf, making it suitable for various industrial applications.

The single-row deep groove design ensures smooth operation and reduces friction during use.
With a maximum speed of 14,000 rpm, it delivers reliable performance in high-speed conditions.

6304 DFGA Bearing operates efficiently within a temperature range of -30°C to 120°C.
Its open seal design allows for easy maintenance and lubrication adjustments when needed.

Application

Common Applications of 6304 DFGA Bearing
In industrial machinery, 6304 DFGA Bearing is widely used in electric motors and pumps, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, extending service life in demanding conditions.

Where Is 6304 DFGA Bearing Used?
You’ll often find 6304 DFGA Bearing in automotive applications like alternators and water pumps, thanks to its reliable performance under high speeds. Its metric sizing makes it a versatile fit for various vehicle models.

Ideal for Precision: 6304 DFGA Bearing
For medical devices such as dental drills, 6304 DFGA Bearing offers consistent performance with minimal noise. The chrome steel construction provides durability in sterile environments.

Automotive vs Industrial: Applications of 6304 DFGA Bearing
In automotive systems, 6304 DFGA Bearing handles radial loads in gearboxes, while in industrial settings, it supports conveyor rollers. Its ABEC 1 tolerance ensures precision across both sectors.

Perfect Fit for Automation: 6304 DFGA Bearing
6304 DFGA Bearing is a go-to choice for robotic arms and CNC machines, where its high-speed capability and low maintenance are key. The chrome steel cage adds extra durability for continuous operation.
