SKF INSOCOAT Bearings 6220M/C4VL0241

SKF INSOCOAT Bearings 6220M/C4VL0241

The SKF INSOCOAT 6220M/C4VL0241 is a robust bearing with a 100mm bore and 180mm outer diameter, featuring a 34mm width. Its outer ring has a special insulation coating to prevent electrical damage.

This model handles dynamic loads up to 127kN and static loads of 93kN, spinning smoothly at speeds up to 7500 RPM. The brass cage ensures durability and stable performance under stress.

The insulation coating provides protection with a breakdown voltage up to 3000V and 200 MΩ resistance, ideal for electric motors or generators. With C4 radial clearance, it accommodates thermal expansion in demanding conditions.

Weighing 3.69kg, it’s a reliable choice for industrial applications where electrical insulation is crucial. Compliant with ROHS standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model 6220M/C4VL0241
  • Product Category INSOCOAT Bearings
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix VL0241
  • Manufacturers SKF
  • Bore Diameter 100.0 mm
  • Outside Diameter 180.0 mm
  • Width 34.0 mm
  • Net Weight 3.69 kg
  • Basic Dynamic Load Rating 127.0 kN
  • Basic Static Load Rating 93.0 kN
  • Reference Speed 7500.0 r/min
  • Breakdown Voltage (DC) ≤3000 V
  • Layer Thickness 500 µm
  • Electrical Resistance 200 MΩ
  • Cage Material Brass cage
  • Radial Internal Clearance C4
  • ROHS Compliant
  • REACH Compliant
SKF INSOCOAT Bearings 6220M/C4VL0241 Drawing.dwg
Download DWG Download PDF

Features

How Is 6220M/C4VL0241 Bearing Engineered for Reliability?

6220M/C4VL0241 Bearing features an insulating coating on the outer ring, protecting against electrical currents.

Its brass cage ensures smooth operation and reduces friction, even at high speeds up to 7,500 r/min.

With a basic dynamic load rating of 127 kN, it handles heavy loads reliably.

The C4 radial internal clearance allows for thermal expansion, making it suitable for varied operating conditions.

Application

Industrial Uses of 6220M/C4VL0241 Bearing
You’ll often spot 6220M/C4VL0241 Bearing in electric motors and generators, where its insulating coating prevents electrical damage from stray currents. The brass cage helps maintain smooth rotation even at high speeds up to 7500 r/min.

What Makes 6220M/C4VL0241 Bearing a Preferred Choice?
In wind turbine systems, 6220M/C4VL0241 Bearing handles heavy radial loads while its C4 clearance accommodates thermal expansion. The 500 µm insulation layer ensures reliable performance in variable weather conditions.

Perfect Fit for Automation: 6220M/C4VL0241 Bearing
This bearing works well in robotic arms where electrical insulation is needed to protect sensitive components. Its 127 kN dynamic load rating provides durability for continuous operation cycles.

Medical vs Industrial: Where 6220M/C4VL0241 Bearing Excels
While suitable for industrial pumps, 6220M/C4VL0241 Bearing’s clean operation also fits medical imaging devices. The VL0241 coating resists corrosion in sterilisation environments.

How Does 6220M/C4VL0241 Bearing Improve Performance?
In railway traction motors, it reduces electrical arcing risks while supporting 93 kN static loads. The 180mm OD fits standard housings without modification.
