Single Row Deep Groove Ball Bearings 6217

Single Row Deep Groove Ball Bearings 6217

The 6217 is a single-row deep groove ball bearing with an 85mm bore and 150mm outer diameter, crafted from sturdy chrome steel for reliable performance. It supports radial loads up to 18884 lbf and operates smoothly at speeds up to 4300 RPM.

Its open design simplifies lubrication, while the stainless steel cage enhances durability. The bearing functions well in temperatures ranging from -30°C to 110°C, making it versatile for various conditions.

This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for applications like electric motors or pumps where radial load handling is key.

Weighing 1740g, it balances strength and manageability. Compliant with RoHS and REACH standards, it’s a safe choice for industrial use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6217
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No CN
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 28 mm
  • Width Tolerance -0.200mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Required
  • REACH Compliant
  • Temperature Range -30° to 110 °C
  • Dynamic Radial Load 18884 lbf
  • Static Radial Load 13916 lbf
  • Max Speed 4300 rpm
  • Weight 1740 g
  • price（$） 32.76
Single Row Deep Groove Ball Bearings 6217 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6217 Bearing

6217 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 18,884 lbf, ensuring reliable performance in various applications.

The stainless steel cage maintains ball alignment, reducing friction and extending service life.
With a maximum speed of 4,300 rpm, it balances durability and efficiency for smooth operation.

6217 Bearing operates effectively in temperatures from -30° to 110°C, suitable for diverse environments.
Its open design simplifies maintenance, though lubrication is required for optimal performance.

The ABEC-1 tolerance class ensures consistent precision, making it a dependable choice for radial load tasks.
Weighing 1,740 g, it provides a sturdy yet manageable solution for industrial use.

Application

Industrial Uses of 6217 Bearing
The 6217 Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. Its open seal allows for easy lubrication, ensuring long service life in demanding conditions.

Where Is 6217 Bearing Used?
You’ll often find the 6217 Bearing in automotive applications such as alternators and wheel hubs, thanks to its reliable performance under radial stress. The chrome steel construction also makes it resistant to wear in high-speed scenarios.

Perfect Fit for Automation: 6217 Bearing
In automated systems, the 6217 Bearing works well in conveyor belts and robotic arms, providing smooth rotation with minimal maintenance. Its ABEC-1 tolerance ensures consistent performance in precision tasks.

Light-Duty vs Heavy-Duty: Best Uses for 6217 Bearing
For light-duty applications like household appliances, the 6217 Bearing offers quiet operation and durability. In heavy-duty settings, such as industrial gearboxes, it handles higher loads without compromising performance.

Medical vs Industrial: Where 6217 Bearing Excels
While not typically used in medical devices, the 6217 Bearing shines in industrial equipment like compressors and fans. Its stainless steel cage and chrome steel rings make it a dependable choice for tough environments.
