Single Row Deep Groove Ball Bearings 6207

Single Row Deep Groove Ball Bearings 6207

The 6207 is a single-row deep groove ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 5778 lbf and operates smoothly at speeds up to 9200 RPM.

Its open design simplifies lubrication, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 288g, it balances lightness with robustness. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6207
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Required
  • REACH Compliant
  • Temperature Range -30° to 110 °C
  • Dynamic Radial Load 5778 lbf
  • Static Radial Load 3462 lbf
  • Max Speed 9200 rpm
  • Weight 288 g
  • price（$） 3.969
Single Row Deep Groove Ball Bearings 6207 dimension drawing
Download DWG Download PDF

Features

How Does 6207 Bearing Reduce Friction?

6207 Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
The chrome steel construction ensures durability while minimising friction during operation.

Its dynamic radial load capacity of 5778 lbf makes it suitable for various industrial applications.
The stainless steel cage maintains ball alignment, reducing wear and extending service life.

With a maximum speed of 9,200 rpm, 6207 Bearing balances efficiency and reliability.
The open seal design allows for easy lubrication, ensuring consistent performance.

Application

Common Applications of 6207 Bearing
The 6207 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its radial load capacity ensures smooth operation. Its open design simplifies lubrication, making maintenance straightforward for busy workshops.

In automotive applications, 6207 Bearing fits well in components like alternators and wheel hubs, thanks to its durable chrome steel construction. The metric sizing makes it a versatile choice for various vehicle models.

For home appliances, 6207 Bearing works reliably in washing machines and fans, handling moderate loads with ease. Its stainless steel cage adds longevity, even in daily use scenarios.

Automation systems often rely on 6207 Bearing for conveyor belts and robotic arms, where consistent performance is key. The ABEC-1 tolerance ensures adequate precision for most general-purpose applications.
