Single Row Deep Groove Ball Bearings 6212-ZNBRJEM (C3)

Single Row Deep Groove Ball Bearings 6212-ZNBRJEM (C3)

The 6212-ZNBRJEM (C3) is a single-row deep groove ball bearing with a 60mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 1178 lbf and operates smoothly at speeds up to 5600 RPM.

Its shielded design keeps out dust and debris, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing 762g, it’s a robust choice for its size. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6212-ZNBRJEM (C3)
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 22 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1178 lbf
  • Static Radial Load 8138 lbf
  • Max Speed 5600 rpm
  • Weight 762 g
Single Row Deep Groove Ball Bearings 6212-ZNBRJEM (C3) dimension drawing
Download DWG Download PDF

Features

Core Advantages of 6212-ZNBRJEM (C3) Bearing

6212-ZNBRJEM (C3) Bearing features a shielded design, protecting against dust and debris while maintaining smooth operation.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

With a dynamic radial load capacity of 1178 lbf, it handles demanding conditions reliably.
The C3 radial clearance provides optimal performance under varying thermal conditions.

Operating within a temperature range of -30°C to 120°C, it adapts to diverse environments.
Its maximum speed of 5,600 rpm balances efficiency with long service life.

The ABEC 1 tolerance class ensures consistent precision for general industrial use.
Its 60 mm bore size accommodates standard shaft dimensions for easy integration.

Application

Industrial Uses of 6212-ZNBRJEM (C3) Bearing
The 6212-ZNBRJEM (C3) Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. Its C3 radial clearance ensures smooth operation even under varying thermal conditions.

In automotive applications, 6212-ZNBRJEM (C3) Bearing fits well in wheel hubs and alternators, thanks to its robust chrome steel construction. The metric sizing makes it a versatile choice for both domestic and international vehicle models.

For automation systems, 6212-ZNBRJEM (C3) Bearing provides reliable performance in robotic arms and conveyor belts. Its ability to handle radial loads efficiently makes it suitable for high-use industrial environments.

Where to Use 6212-ZNBRJEM (C3) Bearing
You’ll often find 6212-ZNBRJEM (C3) Bearing in household appliances like washing machines, where its durability ensures long-lasting performance. The shielded design also helps reduce maintenance needs in dusty environments.

In medical devices, 6212-ZNBRJEM (C3) Bearing offers consistent operation in equipment like centrifuges. Its chrome steel components provide the necessary reliability for precision applications.
