Single Row Deep Groove Ball Bearings 61801-2Z/GFF/R806

Single Row Deep Groove Ball Bearings 61801-2Z/GFF/R806

The 61801-2Z/GFF/R806 is a compact single row deep groove ball bearing, measuring 12mm by 21mm by 5mm. Made from chrome steel, it offers reliable performance for radial loads up to 391 lbf.

Its shielded design keeps out dust and debris, while the ABEC 1 tolerance ensures smooth operation. With a maximum speed of 43,000 RPM, it’s suited for high-speed applications.

This bearing works well in temperatures from -30°C to 120°C and is interchangeable with SKF models. Its lightweight construction (just 0.0063kg) makes it easy to handle.

Ideal for small machinery or electric motors where space is limited. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 61801-2Z/GFF/R806
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.007mm to 0
  • Outer Dia 21 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 5 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 391 lbf
  • Static Radial Load 206 lbf
  • Max Speed 43000 rpm
  • Weight 0.0063 kg
Single Row Deep Groove Ball Bearings 61801-2Z/GFF/R806 dimension drawing
Download DWG Download PDF

Features

Performance Features of 61801-2Z/GFF/R806 Bearing

61801-2Z/GFF/R806 Bearing is designed with chrome steel rings and balls, offering reliable radial load support.
Its dynamic radial load capacity reaches 391 lbf, making it suitable for various applications.
The shielded design helps protect against contaminants, ensuring smoother operation.
With a maximum speed of 43,000 rpm, it balances performance and durability.

Why Choose 61801-2Z/GFF/R806 Bearing for Precision Tasks?

61801-2Z/GFF/R806 Bearing’s compact size (12 mm×21 mm×5 mm) makes it ideal for precision instruments.
The chrome steel construction ensures resistance to wear, extending its service life.
Its ABEC 1 tolerance class provides consistent performance in radial load applications.
The shielded seals help keep out dust and debris, reducing maintenance needs.

Engineered for Precision: 61801-2Z/GFF/R806 Bearing

61801-2Z/GFF/R806 Bearing is built for high-speed applications, reaching up to 43,000 rpm.
The chrome steel cage maintains ball alignment, ensuring smooth and quiet operation.
Its temperature range of -30° to 120°C allows for reliable performance in various environments.
The shielded design offers added protection, making it a practical choice for many uses.

Steel vs Ceramic Bearings: Strengths of 61801-2Z/GFF/R806 Bearing

61801-2Z/GFF/R806 Bearing uses chrome steel for both rings and balls, providing excellent durability.
Its static radial load capacity of 206 lbf ensures stability in demanding conditions.
The shielded design helps prevent contamination, reducing wear over time.
With a lightweight construction (0.0063 kg), it is easy to integrate into various systems.

Application

Common Applications of 61801-2Z/GFF/R806 Bearing
In industrial settings, 61801-2Z/GFF/R806 Bearing is commonly used in small motors and pumps, where its shielded design helps keep contaminants out. The compact size makes it ideal for tight spaces without sacrificing performance.

Where Is 61801-2Z/GFF/R806 Bearing Used?
You’ll often find 61801-2Z/GFF/R806 Bearing in automotive applications like alternators and cooling fans, thanks to its reliable radial load handling. The chrome steel construction ensures longevity even in high-temperature environments.

Perfect Fit for Automation: 61801-2Z/GFF/R806 Bearing
For robotics and automation, 61801-2Z/GFF/R806 Bearing works well in small joints and actuators, providing smooth movement. Its lightweight design is a bonus for precision equipment.

Medical vs Industrial: Where 61801-2Z/GFF/R806 Bearing Excels
In medical devices like dental tools, 61801-2Z/GFF/R806 Bearing offers quiet operation and low friction. Industrial uses include conveyor rollers, where its durability shines under continuous use.
