Single Row Deep Groove Ball Bearings 6212-2Z/C4GXN

Single Row Deep Groove Ball Bearings 6212-2Z/C4GXN

The 6212-2Z/C4GXN is a single-row deep groove ball bearing with a 60mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 1178 lbf and operates smoothly at speeds up to 5600 RPM.

Its shielded design keeps dirt out while maintaining easy access for lubrication. The chrome steel cage adds durability, making it suitable for long-term use in various conditions.

With a C4 radial clearance, it accommodates slight misalignments and thermal expansion. This model is interchangeable with SKF bearings, offering a reliable replacement option.

Ideal for applications like electric motors or pumps where consistent radial load support is needed. It works in temperatures from -30°C to 120°C and complies with RoHS and REACH standards.

Weighing 762g, it balances strength and practicality for industrial use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6212-2Z/C4GXN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C4
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 22 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1178 lbf
  • Static Radial Load 8138 lbf
  • Max Speed 5600 rpm
  • Weight 762 g
Single Row Deep Groove Ball Bearings 6212-2Z/C4GXN dimension drawing
Download DWG Download PDF

Features

Performance Features of 6212-2Z/C4GXN Bearing

6212-2Z/C4GXN Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 1178 lbf, ensuring steady performance in various applications.

The shielded design of 6212-2Z/C4GXN Bearing protects against dust and debris, enhancing durability.
With a maximum speed of 5,600 rpm, it balances efficiency and reliability.

6212-2Z/C4GXN Bearing operates smoothly in temperatures ranging from -30°C to 120°C.
Its chrome steel cage maintains ball alignment, reducing wear and extending service life.

The C4 radial clearance in 6212-2Z/C4GXN Bearing ensures optimal performance under varying loads.
This makes it a versatile choice for industrial and mechanical applications.

Application

Industrial Uses of 6212-2Z/C4GXN Bearing
6212-2Z/C4GXN Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The C4 radial clearance ensures smooth operation even under varying thermal conditions.

What Makes 6212-2Z/C4GXN Bearing a Preferred Choice?
In automotive applications, 6212-2Z/C4GXN Bearing works well in alternators and wheel hubs due to its balanced radial load capacity. The chrome steel construction offers good wear resistance for long-term use.

Perfect Fit for Automation: 6212-2Z/C4GXN Bearing
For automated systems, 6212-2Z/C4GXN Bearing provides reliable performance in conveyor belts and robotic arms. Its metric sizing makes it easy to integrate into various European and Asian equipment designs.

Light-Duty vs Heavy-Duty: Best Uses for 6212-2Z/C4GXN Bearing
In light-duty applications like household appliances, 6212-2Z/C4GXN Bearing ensures quiet operation for devices such as washing machines. For heavier tasks, it handles moderate loads in industrial fans without compromising efficiency.
