Self Aligning Ball Bearings 1322-K-M-C3

Self Aligning Ball Bearings 1322-K-M-C3

The 1322-K-M-C3 is a self-aligning ball bearing with a 110mm tapered bore and 240mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 36675 lbf and operates smoothly at speeds up to 3600 RPM.

Its double-row design and brass cage provide durability, while the open seal allows for easy lubrication. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy-duty applications like industrial fans or conveyor systems where radial loads and slight misalignments occur.

Weighing 11.5kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1322-K-M-C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 110 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 240 mm
  • Outer Dia Tolerance -0.03mm to 0
  • Width 50 mm
  • Width Tolerance -0.2mm to 0
  • External Diameter On Inner Ring 154.35 mm
  • Internal Diameter On Outer Ring 202.9 mm
  • Chamfer Dimension 3 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 36675 lbf
  • Static Radial Load 16200 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 3600 rpm
  • Weight 11.5 kg
  • Price（$） 907.58
Self Aligning Ball Bearings 1322-K-M-C3 dimension drawing
Download DWG Download PDF

Features

How Is 1322-K-M-C3 Bearing Engineered for Reliability?

1322-K-M-C3 Bearing features a double-row design with chrome steel rings and balls, offering robust radial load capacity up to 36675 lbf.

Its brass cage ensures smooth ball alignment, reducing friction and enhancing durability.

The tapered bore design allows for secure fitting, making it suitable for high-precision applications.

With a maximum speed of 3,600 rpm, it delivers consistent performance in various industrial settings.

Application

Common Applications of 1322-K-M-C3 Bearing
In industrial settings, 1322-K-M-C3 Bearing is frequently used in heavy machinery like paper mills and mining equipment, where its self-aligning feature compensates for shaft misalignment. The brass cage ensures smooth operation even under high radial loads.

Where Is 1322-K-M-C3 Bearing Used?
You’ll often find 1322-K-M-C3 Bearing in conveyor systems and gearboxes, where its double-row design handles significant radial forces. The tapered bore allows for secure mounting on shafts, reducing slippage during operation.

Built for Heavy-Duty Use: 1322-K-M-C3 Bearing
This bearing excels in applications like wind turbines and large pumps, thanks to its chrome steel construction and C3 radial clearance. The lubricated design helps maintain performance in demanding environments.

Automotive vs Industrial: Applications of 1322-K-M-C3 Bearing
While 1322-K-M-C3 Bearing isn’t common in cars, it’s ideal for industrial vehicles like forklifts and tractors. Its robust design handles uneven loads, making it reliable for off-road conditions.

Perfect Fit for Automation: 1322-K-M-C3 Bearing
In robotic arms and automated assembly lines, 1322-K-M-C3 Bearing’s self-aligning capability ensures precise movement. The metric sizing makes it easy to integrate into European and Asian machinery designs.
