Single Row Deep Groove Ball Bearings 6211-2ZJEM

Single Row Deep Groove Ball Bearings 6211-2ZJEM

The 6211-2ZJEM is a single-row deep groove ball bearing with a 55mm bore and 100mm outer diameter, crafted from sturdy chrome steel for lasting performance. It handles radial loads up to 9757 lbf and operates smoothly at speeds up to 6300 RPM.

Its shielded design keeps out dust and debris, while the chrome steel cage ensures durability. The bearing works reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 599g, it offers a good balance of strength and manageability. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6211-2ZJEM
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 21 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 9757 lbf
  • Static Radial Load 6609 lbf
  • Max Speed 6300 rpm
  • Weight 599 g
  • price（$） 14.571
Single Row Deep Groove Ball Bearings 6211-2ZJEM dimension drawing
Download DWG Download PDF

Features

Why Choose 6211-2ZJEM Bearing for Precision Tasks?

6211-2ZJEM Bearing features a shielded design, protecting against contaminants while maintaining smooth operation.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

With a dynamic radial load capacity of 9757 lbf, it handles demanding tasks with ease.
The bearing operates efficiently at speeds up to 6,300 rpm, balancing performance and longevity.

6211-2ZJEM Bearing’s ABEC 1 tolerance class guarantees consistent precision for critical applications.
Its temperature range of -30°C to 120°C makes it suitable for various operating conditions.

The shielded design reduces maintenance needs, saving time and costs.
Its interchangeable compatibility with SKF bearings offers flexibility in replacements.

Application

Common Applications of 6211-2ZJEM Bearing
6211-2ZJEM Bearing is widely used in industrial machinery, such as electric motors and pumps, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in demanding environments.

In automotive applications, 6211-2ZJEM Bearing fits well in wheel hubs and alternators, providing reliable radial load support. Its metric sizing makes it compatible with various vehicle models.

For home appliances like washing machines, 6211-2ZJEM Bearing offers smooth operation and long service life. The shielded seals help protect against dust and moisture, extending its performance.

In automation systems, 6211-2ZJEM Bearing is often found in conveyor belts and robotic arms. Its balanced design ensures consistent performance under varying loads.
