Single Row Deep Groove Ball Bearings 61812-2RS1/W64

Single Row Deep Groove Ball Bearings 61812-2RS1/W64

The 61812-2RS1/W64 is a compact single-row deep groove ball bearing with a 60mm bore and 78mm outer diameter, built from sturdy chrome steel. It manages radial loads up to 2675 lbf and spins smoothly at speeds up to 11000 RPM.

Its sealed design keeps dirt out and solid oil lubrication ensures long service life without frequent maintenance. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a reliable alternative for replacements. Perfect for small electric motors or appliances where space is limited but performance is key.

Weighing just 0.095kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 61812-2RS1/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 78 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 10 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2675 lbf
  • Static Radial Load 2563 lbf
  • Max Speed 11000 rpm
  • Weight 0.095 kg
  • price（$） 60.93
Single Row Deep Groove Ball Bearings 61812-2RS1/W64 dimension drawing
Download DWG Download PDF

Features

Performance Features of 61812-2RS1/W64 Bearing

61812-2RS1/W64 Bearing is designed for radial loads, with a dynamic radial load capacity of 2675 lbf.
Its sealed construction and solid oil lubrication ensure smooth operation with minimal maintenance.
The chrome steel rings and balls enhance durability, making it suitable for various applications.
With a maximum speed of 11,000 rpm, it offers reliable performance in demanding conditions.

Application

Industrial Uses of 61812-2RS1/W64 Bearing
61812-2RS1/W64 Bearing is commonly used in conveyor systems, where its sealed design protects against dust and debris. The solid oil lubrication ensures long service life, even in continuous operation.

Where Is 61812-2RS1/W64 Bearing Used?
You’ll often find 61812-2RS1/W64 Bearing in electric motors, thanks to its reliable radial load handling. Its compact size makes it ideal for space-constrained applications.

Built for Heavy-Duty Use: 61812-2RS1/W64 Bearing
61812-2RS1/W64 Bearing excels in industrial fans, where its chrome steel construction withstands high speeds. The ABEC 1 tolerance ensures consistent performance under varying loads.

Automotive vs Aerospace: Applications of 61812-2RS1/W64 Bearing
In automotive systems, 61812-2RS1/W64 Bearing supports alternators and pumps, while its temperature range suits aerospace auxiliary equipment. The sealed design prevents contamination in both environments.

Perfect Fit for Automation: 61812-2RS1/W64 Bearing
61812-2RS1/W64 Bearing works well in robotic arms, where its low maintenance needs reduce downtime. The solid oil lubrication keeps it running smoothly in repetitive motions.
