Single Row Deep Groove Ball Bearings 61807

Single Row Deep Groove Ball Bearings 61807

The 61807 is a compact single-row deep groove ball bearing with a 35mm bore and 47mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 980 lbf and spins smoothly at speeds up to 18,000 RPM.

Its open design allows for easy lubrication, while the stainless steel cage ensures durability. The bearing operates efficiently in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Perfect for applications like small motors or precision instruments where space is limited.

Weighing just 0.029kg, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 61807
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 980 lbf
  • Static Radial Load 753 lbf
  • Max Speed 18000 rpm
  • Weight 0.029 kg
  • price（$） 18.162
Single Row Deep Groove Ball Bearings 61807 dimension drawing
Download DWG Download PDF

Features

How Does 61807 Bearing Reduce Friction?

61807 Bearing features a single-row deep groove design, optimised for smooth radial load handling.
The chrome steel construction ensures durability while minimising friction during operation.

With a dynamic radial load capacity of 980 lbf, it performs reliably in various applications.
Its compact size (35 mm×47 mm×7 mm) makes it suitable for space-constrained installations.

The stainless steel cage maintains ball alignment, reducing wear and extending service life.
Operating temperatures range from -30° to 120°C, ensuring versatility in different environments.

A maximum speed of 18,000 rpm allows for efficient performance in high-speed applications.
The open seal design simplifies maintenance while maintaining consistent operation.

Application

Industrial Uses of 61807 Bearing
61807 Bearing is commonly used in small electric motors and pumps, where its compact size and radial load capacity are ideal. The open design allows for easy lubrication, extending service life in continuous operation.

What Makes 61807 Bearing a Preferred Choice?
With its chrome steel construction, 61807 Bearing offers reliable performance in household appliances like washing machines. The P6 tolerance ensures smooth rotation, reducing noise in daily use.

Perfect Fit for Automation: 61807 Bearing
In robotic arms and small conveyors, 61807 Bearing provides precise movement thanks to its single-row deep groove design. Its lightweight build also helps in reducing overall system energy consumption.

Automotive vs Industrial: Applications of 61807 Bearing
For automotive auxiliary units like alternators, 61807 Bearing handles moderate radial loads efficiently. In industrial settings, it’s equally suited for light machinery where space is limited.

Medical vs Consumer Electronics: Where 61807 Bearing Excels
In medical devices like small centrifuges, 61807 Bearing’s stainless steel cage ensures hygiene and durability. Meanwhile, printers and scanners benefit from its quiet operation and consistent performance.
