Single Row Deep Groove Ball Bearings 61807/C4

Single Row Deep Groove Ball Bearings 61807/C4

The 61807/C4 is a single-row deep groove ball bearing with a 35mm bore and 47mm outer diameter, crafted from sturdy chrome steel for durability. It handles radial loads up to 980 lbf and spins smoothly at speeds up to 18,000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures reliable performance. The bearing operates efficiently in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or small machinery where radial loads are common.

Weighing just 0.029kg, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 61807/C4
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C4
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 980 lbf
  • Static Radial Load 753 lbf
  • Max Speed 18000 rpm
  • Weight 0.029 kg
  • price（$） 18.162
Single Row Deep Groove Ball Bearings 61807/C4 dimension drawing
Download DWG Download PDF

Features

Performance Features of 61807/C4 Bearing

61807/C4 Bearing is crafted with chrome steel rings and balls, offering excellent radial load capacity.
Its dynamic radial load rating of 980 lbf ensures steady performance in various applications.

The open design allows for easy lubrication, enhancing its operational efficiency.
With a maximum speed of 18,000 rpm, it suits high-speed machinery while maintaining durability.

61807/C4 Bearing operates smoothly in temperatures ranging from -30°C to 120°C.
Its C4 radial clearance provides flexibility in different operating conditions.

Application

Industrial Uses of 61807/C4 Bearing
61807/C4 Bearing is commonly used in conveyor systems and small electric motors, where its single-row design ensures smooth radial load handling. The open seal allows for easy lubrication, making it suitable for dusty environments.

In automotive applications, 61807/C4 Bearing fits well in alternators and cooling fans, providing reliable performance under moderate loads. Its C4 clearance helps accommodate thermal expansion in high-speed scenarios.

For home appliances like washing machines, 61807/C4 Bearing’s compact size and durability make it a practical choice. The chrome steel construction ensures long-lasting performance even with frequent use.

Where Is 61807/C4 Bearing Used?
You’ll find 61807/C4 Bearing in office equipment such as printers and scanners, where its low noise operation is a plus. The ABEC 1 tolerance ensures consistent performance without unnecessary complexity.

In light industrial machinery, 61807/C4 Bearing handles radial loads efficiently, thanks to its deep groove design. The wide temperature range also makes it versatile for various operating conditions.
