Single Row Deep Groove Ball Bearings 609-2Z

Single Row Deep Groove Ball Bearings 609-2Z

The 609-2Z is a compact single-row deep groove ball bearing, measuring 9mm by 24mm by 7mm, crafted from sturdy chrome steel. It supports radial loads up to 877 lbf and can spin at speeds up to 34,000 RPM.

Its shielded design keeps grease in and dirt out, making it low-maintenance. The stainless steel cage adds durability, ensuring smooth operation even under stress.

This bearing works well in temperatures from -30°C to 120°C, suitable for various environments. It’s interchangeable with SKF models, offering a reliable replacement option.

Ideal for small motors or appliances where space is limited but performance is key. Compliant with RoHS and REACH standards, it’s both safe and dependable.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 609-2Z
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 9 mm
  • Bore Dia Tolerance -0.007mm to 0
  • Outer Dia 24 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 877 lbf
  • Static Radial Load 373 lbf
  • Max Speed 34000 rpm
  • Weight 0.015 kg
  • price（$） 1.197
Single Row Deep Groove Ball Bearings 609-2Z dimension drawing
Download DWG Download PDF

Features

Performance Features of 609-2Z Bearing

609-2Z Bearing is designed with chrome steel rings and balls, offering reliable radial load support.
Its dynamic radial load capacity of 877 lbf ensures steady performance in various applications.
The shielded design protects against contaminants while maintaining smooth operation.
With a maximum speed of 34,000 rpm, it balances efficiency and durability.

How Does 609-2Z Bearing Reduce Friction?

609-2Z Bearing features a single-row deep groove design, minimising friction during operation.
The stainless steel cage keeps the balls aligned, reducing wear and enhancing efficiency.
Grease lubrication further lowers friction, ensuring quiet and smooth performance.
Its P6 tolerance class guarantees precision in demanding conditions.

Built for Reliability: 609-2Z Bearing

609-2Z Bearing’s chrome steel construction provides excellent resistance to wear and tear.
The shielded seals protect against dust and debris, extending its service life.
It operates smoothly within a temperature range of -30° to 120°C.
This makes it suitable for a wide range of industrial applications.

Application

Common Applications of 609-2Z Bearing
In industrial machinery, 609-2Z Bearing is a reliable choice for small electric motors and pumps, thanks to its shielded design that keeps contaminants out. Its compact size makes it ideal for tight spaces where precision matters.

Where Is 609-2Z Bearing Used?
You’ll often find 609-2Z Bearing in household appliances like washing machines and fans, where its smooth operation and durability are key. The grease lubrication ensures quiet performance, perfect for daily use.

Optimized for Performance: 609-2Z Bearing
For light-duty automation equipment, 609-2Z Bearing offers consistent radial load support, ensuring reliable motion control. Its stainless steel cage adds longevity, even in continuous operation.

Automotive vs Industrial: Applications of 609-2Z Bearing
In automotive applications, 609-2Z Bearing fits well in small gearboxes and alternators, while in industrial settings, it’s suited for conveyor rollers. The metric sizing ensures easy integration across various systems.
