Single Row Deep Groove Ball Bearings 6017-2Z

Single Row Deep Groove Ball Bearings 6017-2Z

The 6017-2Z is a single-row deep groove ball bearing with an 85mm bore and 130mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 11690 lbf and operates smoothly at speeds up to 5300 RPM.

Shielded on both sides, it keeps grease in and contaminants out, making it low-maintenance. The stainless steel cage adds durability, while the P6 tolerance ensures precise performance.

This bearing suits temperatures from -30°C to 120°C and is interchangeable with SKF models. Ideal for electric motors or pumps where reliable radial load support is needed.

Weighing 0.94kg, it’s a robust choice for industrial applications. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6017-2Z
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 130 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 22 mm
  • Width Tolerance -0.2mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 11690 lbf
  • Static Radial Load 9667 lbf
  • Max Speed 5300 rpm
  • Weight 0.94 kg
  • price（$） 29.16
Single Row Deep Groove Ball Bearings 6017-2Z dimension drawing
Download DWG Download PDF

Features

Performance Features of 6017-2Z Bearing

6017-2Z Bearing is designed for radial loads, with a dynamic radial load capacity of 11690 lbf.

Its chrome steel construction ensures durability and resistance to wear in various applications.

The shielded design protects against contaminants, making it suitable for harsh environments.

With a maximum speed of 5,300 rpm, it offers reliable performance for industrial use.

Application

Common Applications of 6017-2Z Bearing
In industrial settings, 6017-2Z Bearing is commonly used in electric motors and pumps, where its shielded design helps keep contaminants out. The grease lubrication ensures smooth operation even in demanding environments.

Where Is 6017-2Z Bearing Used?
You’ll often find 6017-2Z Bearing in automotive applications like alternators and water pumps, thanks to its reliable radial load handling. Its P6 tolerance class makes it suitable for precision components.

Built for Heavy-Duty Use: 6017-2Z Bearing
For machinery requiring consistent performance, 6017-2Z Bearing’s chrome steel construction offers durability. The stainless steel cage adds extra resistance to wear, making it a solid choice for long-term use.

Automotive vs Industrial: Applications of 6017-2Z Bearing
In cars, 6017-2Z Bearing supports components like fans and pulleys, while in factories, it’s ideal for conveyor systems. Its metric sizing ensures compatibility across various equipment types.

Perfect Fit for Automation: 6017-2Z Bearing
In automated systems, 6017-2Z Bearing works well in robotic arms and assembly lines. The shielded seals protect against dust, maintaining performance in high-use scenarios.
