Single Row Deep Groove Ball Bearings 6015-ZJEM

Single Row Deep Groove Ball Bearings 6015-ZJEM

The 6015-ZJEM is a single-row deep groove ball bearing with a 75mm bore and 115mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 8902 lbf and operates smoothly at speeds up to 5600 RPM.

Its shielded design keeps dirt out while maintaining smooth rotation, and the chrome steel cage adds durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing 638g, it’s a robust choice for its size. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6015-ZJEM
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 75 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 115 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 8902 lbf
  • Static Radial Load 7531 lbf
  • Max Speed 5600 rpm
  • Weight 638 g
  • price（$） 29.844
Single Row Deep Groove Ball Bearings 6015-ZJEM dimension drawing
Download DWG Download PDF

Features

Performance Features of 6015-ZJEM Bearing

6015-ZJEM Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 8902 lbf, ensuring reliable performance in various applications.

The shielded design of 6015-ZJEM Bearing protects against contaminants, enhancing durability.
With a maximum speed of 5,600 rpm, it balances efficiency and long-term use.

6015-ZJEM Bearing operates smoothly in temperatures ranging from -30°C to 120°C.
Its precision construction meets ABEC 1 and ISO P0 standards for consistent performance.

Application

Industrial Uses of 6015-ZJEM Bearing
The 6015-ZJEM Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. Its chrome steel construction ensures durability in demanding environments.

How Does 6015-ZJEM Bearing Improve Performance?
In automotive applications, 6015-ZJEM Bearing enhances performance in components such as alternators and water pumps. Its radial load capacity and smooth operation make it a reliable choice for long-term use.

Built for Heavy-Duty Use: 6015-ZJEM Bearing
This bearing is ideal for conveyor systems and gearboxes, handling radial loads with ease. The ABEC 1 tolerance ensures consistent performance without unnecessary complexity.

Automotive vs Industrial: Applications of 6015-ZJEM Bearing
In automotive settings, 6015-ZJEM Bearing works well in wheel hubs and transmissions. For industrial use, it’s suited for machinery requiring reliable radial load support.

Perfect Fit for Automation: 6015-ZJEM Bearing
The 6015-ZJEM Bearing is a great match for robotic arms and automated assembly lines. Its shielded design and chrome steel materials provide both protection and longevity.
