Single Row Deep Groove Ball Bearings 6210-2RS1/C2GJN

Single Row Deep Groove Ball Bearings 6210-2RS1/C2GJN

The 6210-2RS1/C2GJN is a single-row deep groove ball bearing with a 50mm bore and 90mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 7891 lbf and operates smoothly at speeds up to 7100 RPM.

Its sealed design keeps dirt out and lubrication in, making it low-maintenance. The chrome steel cage adds strength and longevity, while the C2 radial clearance ensures smooth rotation.

This bearing works well in temperatures from -30°C to 120°C, suitable for various environments. It’s interchangeable with SKF models, offering a reliable replacement option.

Ideal for applications like electric motors or pumps where radial loads are common. Weighing 463g, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6210-2RS1/C2GJN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C2
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 7891 lbf
  • Static Radial Load 5238 lbf
  • Max Speed 7100 rpm
  • Weight 463 g
  • price（$） 13.716
Single Row Deep Groove Ball Bearings 6210-2RS1/C2GJN dimension drawing
Download DWG Download PDF

Features

Performance Features of 6210-2RS1/C2GJN Bearing

6210-2RS1/C2GJN Bearing is designed for radial loads, with a dynamic radial load capacity of 7891 lbf.
Its sealed construction keeps contaminants out, ensuring smooth operation in various environments.
The chrome steel rings and balls provide durability, while the C2 radial clearance offers optimal performance.
With a maximum speed of 7,100 rpm, it balances efficiency and reliability.

Application

Common Applications of 6210-2RS1/C2GJN Bearing
In industrial machinery, 6210-2RS1/C2GJN Bearing is widely used in electric motors and pumps, thanks to its sealed design that keeps contaminants out. The C2 radial clearance ensures smooth operation even under moderate loads.

Where Is 6210-2RS1/C2GJN Bearing Used?
You’ll often find 6210-2RS1/C2GJN Bearing in automotive applications like alternators and water pumps, where its chrome steel construction offers long-lasting performance. The metric sizing makes it a versatile fit for various vehicle models.

Ideal for Precision: 6210-2RS1/C2GJN Bearing
For medical devices such as dental drills, 6210-2RS1/C2GJN Bearing provides reliable rotation with minimal maintenance. Its sealed design is particularly useful in environments where hygiene is a priority.

Automotive vs Industrial: Applications of 6210-2RS1/C2GJN Bearing
In automotive systems, 6210-2RS1/C2GJN Bearing handles radial loads in components like fans and compressors. Meanwhile, in industrial settings, it’s a go-to for conveyor systems and gearboxes due to its durability.

Practical Applications of 6210-2RS1/C2GJN Bearing
For household appliances like washing machines, 6210-2RS1/C2GJN Bearing ensures quiet and efficient operation. The sealed design helps protect against dust and moisture, extending its lifespan.
