Single Row Deep Groove Ball Bearings 6000/VK315

The 6000/VK315 is a compact single-row deep groove ball bearing with a 10mm bore and 26mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 1023 lbf and spins efficiently at speeds up to 31,000 RPM.

Its open design simplifies maintenance, while the chrome steel cage ensures durability. The bearing operates smoothly in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Perfect for small machinery or electric motors where space is limited but performance is key.

Weighing just 19g, it’s lightweight yet robust. Compliant with RoHS and REACH standards, it’s a safe choice for various applications.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6000/VK315
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Open
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No CN
Bore Dia 10 mm
Bore Dia Tolerance -0.008mm to 0
Outer Dia 26 mm
Outer Dia Tolerance -0.009mm to 0
Width 8 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 1023 lbf
Static Radial Load 438 lbf
Max Speed 31000 rpm
Weight 19 g

Single Row Deep Groove Ball Bearings 6000/VK315 dimension drawing

Download DWG Download PDF

Features

Performance Features of 6000/VK315 Bearing

6000/VK315 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 1023 lbf, ensuring steady performance in various applications.

The single-row deep groove design enhances load distribution, reducing stress on the bearing.
With a maximum speed of 31,000 rpm, it delivers efficient and reliable operation.

6000/VK315 Bearing operates smoothly in temperatures ranging from -30°C to 120°C.
Its open design allows for easy maintenance and lubrication, extending service life.

Application

Common Applications of 6000/VK315 Bearing
In industrial settings, 6000/VK315 Bearing is widely used in electric motors and pumps due to its reliable radial load capacity. The open design simplifies lubrication, making it suitable for continuous operation.

Where Is 6000/VK315 Bearing Used?
You’ll often find 6000/VK315 Bearing in automotive components like alternators and small gearboxes. Its compact size and metric dimensions make it a versatile fit for various vehicle models.

Ideal for Precision: 6000/VK315 Bearing
For medical devices such as dental drills, 6000/VK315 Bearing offers smooth rotation and durability. The chrome steel construction ensures long-term performance in high-precision applications.

Automotive vs Industrial: Applications of 6000/VK315 Bearing
In automotive systems, 6000/VK315 Bearing handles radial loads in small engines, while in industrial fans, it supports consistent rotation. Its ABEC 1 tolerance balances cost and performance.

Practical Applications of 6000/VK315 Bearing
In home appliances like washing machines, 6000/VK315 Bearing provides quiet and efficient operation. The lightweight design (19g) minimises energy consumption without compromising durability.
