Single Row Deep Groove Ball Bearings 6305-2RS1/C3

Single Row Deep Groove Ball Bearings 6305-2RS1/C3

The 6305-2RS1/C3 is a single-row deep groove ball bearing with a 25mm bore and 62mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 4631 lbf and operates smoothly at speeds up to 11000 RPM.

Its sealed design keeps out dust and moisture, extending its lifespan, while the C3 radial clearance allows for thermal expansion in various conditions. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or pumps where consistent radial load support is needed.

Weighing 232g, it’s a sturdy yet manageable option for its size. Compliant with RoHS and REACH standards, it’s safe for widespread industrial use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6305-2RS1/C3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4631 lbf
  • Static Radial Load 254 lbf
  • Max Speed 11000 rpm
  • Weight 232 g
  • price（$） 5.121
Single Row Deep Groove Ball Bearings 6305-2RS1/C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6305-2RS1/C3 Bearing

6305-2RS1/C3 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 4631 lbf.
Its sealed design protects against dust and moisture, ensuring smooth operation in various environments.

The C3 radial clearance allows for thermal expansion, making it suitable for high-speed applications up to 11,000 rpm.
With a temperature range of -30°C to 120°C, it performs reliably in diverse conditions.

6305-2RS1/C3 Bearing’s single-row deep groove design ensures low friction and quiet operation.
Its chrome steel cage enhances durability, reducing maintenance needs over time.

Application

Industrial Uses of 6305-2RS1/C3 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its sealed design helps keep contaminants out. The C3 clearance ensures reliable performance even under varying thermal conditions.

Where Is 6305-2RS1/C3 Bearing Used?
You’ll find this bearing in automotive applications such as alternators and wheel hubs, thanks to its radial load capacity. The chrome steel construction offers durability for long-term use in demanding environments.

Perfect Fit for Automation: 6305-2RS1/C3 Bearing
In robotic arms and conveyor systems, this bearing provides smooth rotation with minimal maintenance. Its sealed design is particularly useful in dusty or wet conditions.

Medical vs Industrial: Where 6305-2RS1/C3 Bearing Excels
While it’s a staple in industrial gear, this bearing also works well in medical devices like centrifuges. The consistent performance and easy installation make it versatile for various settings.

How Does 6305-2RS1/C3 Bearing Support High-Speed Operations?
With a max speed of 11,000 rpm, this bearing is ideal for applications like small turbines or high-speed spindles. The balanced design reduces vibration for smoother operation.
