Single Row Deep Groove Ball Bearings 310MZ-0001

Single Row Deep Groove Ball Bearings 310MZ-0001

The 310MZ-0001 is a single-row deep groove ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel for durability. It supports radial loads up to 14478 lbf and operates smoothly at speeds up to 7000 RPM.

Its shielded design keeps out dust and debris, while the chrome steel cage enhances longevity. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 1.15kg, it balances strength and manageability. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 310MZ-0001
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 27 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 14478 lbf
  • Static Radial Load 11690 lbf
  • Max Speed 7000 rpm
  • Weight 1.15 kg
  • price（$） 24.822
Single Row Deep Groove Ball Bearings 310MZ-0001 dimension drawing
Download DWG Download PDF

Features

Performance Features of 310MZ-0001 Bearing

310MZ-0001 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 14478 lbf, ensuring reliable performance in various applications.

The shielded design of 310MZ-0001 Bearing protects against contaminants, enhancing durability.
With a maximum speed of 7,000 rpm, it balances efficiency and longevity.

310MZ-0001 Bearing operates in temperatures from -30°C to 120°C, suitable for diverse environments.
Its ABEC 1 tolerance ensures consistent performance without compromising precision.

The chrome steel cage maintains ball alignment, reducing wear and extending service life.
This design makes 310MZ-0001 Bearing a practical choice for industrial and mechanical uses.

Application

Industrial Uses of 310MZ-0001 Bearing
310MZ-0001 Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability even in demanding environments.

In automotive applications, 310MZ-0001 Bearing fits well in wheel hubs and transmission systems, providing reliable radial load support. Its ABEC 1 tolerance makes it suitable for standard precision requirements.

For automation equipment, 310MZ-0001 Bearing works smoothly in robotic arms and conveyor belts, thanks to its balanced performance. The metric sizing ensures easy integration with various machinery components.

Where Is 310MZ-0001 Bearing Used?
You’ll often find 310MZ-0001 Bearing in household appliances like washing machines, where its shielded design prolongs lifespan. The chrome steel cage adds extra resistance to wear and tear.

In medical devices, 310MZ-0001 Bearing offers consistent performance in equipment like centrifuges. Its temperature range allows it to handle both low and moderate heat conditions effectively.

Built for Heavy-Duty Use: 310MZ-0001 Bearing
310MZ-0001 Bearing handles radial loads efficiently in construction equipment like gearboxes. The static radial load capacity ensures stability under heavy use.

For consumer electronics, 310MZ-0001 Bearing is a reliable choice in printers and scanners. Its compact size and shielded design make it ideal for space-constrained applications.
