Single Row Deep Groove Ball Bearings 6316-2Z/C3GHE

Single Row Deep Groove Ball Bearings 6316-2Z/C3GHE

The 6316-2Z/C3GHE is a single-row deep groove ball bearing with an 80mm bore and 170mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 27652 lbf and operates smoothly at speeds up to 4000 RPM.

Shielded on both sides, it offers good protection against dust and debris, while the C3 clearance ensures reliable performance under varying temperatures. The bearing works well in environments ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads are common.

Weighing 3.67kg, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6316-2Z/C3GHE
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 80 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 170 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 39 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 27652 lbf
  • Static Radial Load 19491 lbf
  • Max Speed 4000 rpm
  • Weight 3670 g
Single Row Deep Groove Ball Bearings 6316-2Z/C3GHE dimension drawing
Download DWG Download PDF

Features

Performance Features of 6316-2Z/C3GHE Bearing

6316-2Z/C3GHE Bearing is built with chrome steel rings and balls, offering robust performance under radial loads.
Its dynamic radial load capacity reaches 27652 lbf, making it suitable for demanding industrial applications.

The shielded design of 6316-2Z/C3GHE Bearing protects against contaminants, ensuring smooth operation.
With a maximum speed of 4,000 rpm, it balances efficiency and durability in various conditions.

6316-2Z/C3GHE Bearing operates in temperatures from -30° to 120°C, adapting to diverse environments.
Its C3 radial clearance provides optimal performance under varying thermal expansions.

The chrome steel cage in 6316-2Z/C3GHE Bearing ensures stability, reducing wear over time.
This design enhances longevity, making it a reliable choice for continuous operation.

Application

Industrial Uses of 6316-2Z/C3GHE Bearing
6316-2Z/C3GHE Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The C3 radial clearance ensures smooth operation even under varying thermal conditions.

In automotive applications, 6316-2Z/C3GHE Bearing fits well in wheel hubs and transmission systems, thanks to its robust chrome steel construction. Its metric sizing makes it a versatile choice for various vehicle models.

For automation equipment, 6316-2Z/C3GHE Bearing provides reliable performance in robotic arms and conveyor belts. The single-row deep groove design handles radial loads efficiently, ensuring long service life.

Where Is 6316-2Z/C3GHE Bearing Used?
You’ll find 6316-2Z/C3GHE Bearing in household appliances like washing machines, where its durability and low maintenance are key. The shielded seals protect against dust and moisture, ideal for everyday use.

In agricultural machinery, 6316-2Z/C3GHE Bearing supports heavy loads in equipment like harvesters. Its high dynamic radial load capacity makes it suitable for demanding outdoor conditions.
