Single Row Deep Groove Ball Bearings 210SZZG

Single Row Deep Groove Ball Bearings 210SZZG

The 210SZZG is a single row deep groove ball bearing with a 50mm bore and 90mm outer diameter, crafted from sturdy chrome steel for reliable performance. It handles radial loads up to 8790 lbf and operates smoothly at speeds up to 8000 RPM.

Its shielded design offers basic protection against dust and debris, while the chrome steel cage enhances durability. The bearing performs well in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for various applications like electric motors or pumps where radial loads are common.

Weighing 0.5kg, it’s a robust yet manageable size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 210SZZG
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 8790 lbf
  • Static Radial Load 7756 lbf
  • Max Speed 8000 rpm
  • Weight 0.5 kg
  • price（$） 16.056
Single Row Deep Groove Ball Bearings 210SZZG dimension drawing
Download DWG Download PDF

Features

Performance Features of 210SZZG Bearing

210SZZG Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 8790 lbf, ensuring reliable performance in various applications.
The shielded design helps protect against contaminants, extending the bearing’s service life.
With a maximum speed of 8,000 rpm, it balances durability and efficiency for smooth operation.

Application

Industrial Uses of 210SZZG Bearing
210SZZG Bearing is commonly used in machine tools and conveyor systems, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in demanding industrial environments.

What Makes 210SZZG Bearing a Preferred Choice?
In automotive applications like electric motors and pumps, 210SZZG Bearing offers reliable radial load support. Its ABEC 1 tolerance makes it suitable for standard precision requirements.

Perfect Fit for Automation: 210SZZG Bearing
This bearing works well in robotic arms and automated assembly lines, thanks to its smooth operation and moderate speed capability. The metric sizing ensures easy integration with European machinery.

Medical vs Industrial: Where 210SZZG Bearing Excels
While not for high-precision medical devices, 210SZZG Bearing performs reliably in industrial washers and packaging equipment. Its temperature range handles most factory conditions comfortably.

Where Is 210SZZG Bearing Used?
You’ll find 210SZZG Bearing in household appliances like washing machines, where its shielded design protects against dust. The static load capacity handles typical domestic use with ease.
