Single Row Deep Groove Ball Bearings 207SG

Single Row Deep Groove Ball Bearings 207SG

The 207SG is a single-row deep groove ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 6182 lbf and operates smoothly at speeds reaching 10,000 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 0.31kg, it balances strength and lightness. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 207SG
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6182 lbf
  • Static Radial Load 4946 lbf
  • Max Speed 10000 rpm
  • Weight 0.31 kg
  • price（$） 8.118
Single Row Deep Groove Ball Bearings 207SG dimension drawing
Download DWG Download PDF

Features

How Does 207SG Bearing Reduce Friction?

207SG Bearing features a single-row deep groove design, optimised for smooth radial load distribution.

Its chrome steel construction ensures durability while minimising friction during operation.

The open seal type allows for easy maintenance, enhancing long-term performance.

With a maximum speed of 10,000 rpm, it balances efficiency and reliability in various applications.

Application

Industrial Uses of 207SG Bearing
207SG Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending service life in demanding environments.

What Makes 207SG Bearing a Preferred Choice?
In automotive applications, 207SG Bearing fits well in alternators and wheel hubs, thanks to its balanced radial load handling. The chrome steel construction provides durability under varying temperatures and speeds.

Perfect Fit for Automation: 207SG Bearing
For robotic arms and conveyor systems, 207SG Bearing offers smooth operation with minimal maintenance. Its ABEC 1 tolerance ensures consistent performance in precision-driven tasks.

Medical vs Industrial: Where 207SG Bearing Excels
While 207SG Bearing suits industrial gearboxes, its clean operation also makes it ideal for medical devices like centrifuges. The ISO P0 tolerance guarantees reliability in sensitive applications.
