Single Row Deep Groove Ball Bearings 207M

Single Row Deep Groove Ball Bearings 207M

The 207M is a single-row deep groove ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 6182 lbf and spins smoothly at speeds up to 10,000 RPM.

Its open design simplifies maintenance, while the chrome steel cage ensures durability. The bearing operates reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or conveyor systems where radial loads are common.

Weighing 0.31kg, it’s a robust yet lightweight option. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 207M
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6182 lbf
  • Static Radial Load 4946 lbf
  • Max Speed 10000 rpm
  • Weight 0.31 kg
  • price（$） 9.072
Single Row Deep Groove Ball Bearings 207M dimension drawing
Download DWG Download PDF

Features

Performance Features of 207M Bearing

207M Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 6182 lbf, ensuring reliable performance in various applications.
The chrome steel cage maintains ball alignment, reducing wear and extending service life.
With a maximum speed of 10,000 rpm, it balances durability and efficiency for smooth operation.

Application

Industrial Uses of 207M Bearing
207M Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending its service life in demanding conditions.

Where Is 207M Bearing Used?
You’ll often find 207M Bearing in automotive applications such as alternators and wheel hubs, thanks to its balanced load handling. Its metric sizing makes it a versatile fit for various vehicle models.

Built for Versatility: 207M Bearing
In automation systems, 207M Bearing supports robotic arms and conveyor belts, providing smooth motion with minimal friction. The chrome steel construction ensures durability even in high-speed operations.

Automotive vs Industrial: Applications of 207M Bearing
207M Bearing works well in both automotive and industrial settings, from gearboxes to machinery spindles. Its ABEC 1 tolerance offers consistent performance without the need for high precision.

Practical Applications of 207M Bearing
For household appliances like washing machines, 207M Bearing offers quiet and efficient operation. The wide temperature range makes it suitable for both hot and cold environments.
