Single Row Deep Groove Ball Bearings 207SFFX

Single Row Deep Groove Ball Bearings 207SFFX

The 207SFFX is a single-row deep groove ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 6182 lbf and operates smoothly at speeds up to 10,000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 0.31kg, it’s a robust yet lightweight option. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 207SFFX
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6182 lbf
  • Static Radial Load 4946 lbf
  • Max Speed 10000 rpm
  • Weight 0.31 kg
  • price（$） 33.111
Single Row Deep Groove Ball Bearings 207SFFX dimension drawing
Download DWG Download PDF

Features

Performance Features of 207SFFX Bearing

207SFFX Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 6182 lbf, ensuring reliable performance in various applications.

The chrome steel cage maintains ball alignment, reducing friction and wear for smoother operation.
With a maximum speed of 10,000 rpm, it balances efficiency and durability in demanding conditions.

207SFFX Bearing operates in temperatures from -30°C to 120°C, suitable for diverse environments.
Its open design simplifies maintenance while providing consistent performance over time.

Application

Industrial Uses of 207SFFX Bearing
207SFFX Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending its service life in demanding conditions.

What Makes 207SFFX Bearing a Preferred Choice?
In automotive applications, 207SFFX Bearing fits well in components such as alternators and wheel hubs, thanks to its balanced load handling. The chrome steel construction provides durability against wear and tear.

Perfect Fit for Automation: 207SFFX Bearing
For robotic arms and automated systems, 207SFFX Bearing offers smooth rotation and low friction. Its metric sizing ensures compatibility with a variety of European and Asian machinery standards.

Medical vs Industrial: Where 207SFFX Bearing Excels
In medical devices like centrifuges, 207SFFX Bearing’s precision and reliability are key. Meanwhile, in industrial settings, it handles radial loads effortlessly, making it versatile across sectors.
