Single Row Deep Groove Ball Bearings 206SZZG

Single Row Deep Groove Ball Bearings 206SZZG

The 206SZZG is a single-row deep groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel for durability. It handles radial loads up to 4699 lbf and can spin at speeds up to 12,000 RPM, making it suitable for high-speed applications.

Its shielded design keeps out dust and debris while maintaining smooth operation. The chrome steel cage adds strength, and the bearing works reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Ideal for use in electric motors, pumps, or small machinery where radial loads are common.

Weighing just 0.21kg, it’s lightweight yet robust. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 206SZZG
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4699 lbf
  • Static Radial Load 3664 lbf
  • Max Speed 12000 rpm
  • Weight 0.21 kg
  • price（$） 5.13
Single Row Deep Groove Ball Bearings 206SZZG dimension drawing
Download DWG Download PDF

Features

Why Choose 206SZZG Bearing for Precision Tasks?

206SZZG Bearing features a shielded design, protecting against contaminants while maintaining smooth operation.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.
With a dynamic radial load capacity of 4699 lbf, it handles demanding tasks with ease.
The bearing operates efficiently at speeds up to 12,000 rpm, making it suitable for high-performance machinery.

Application

Industrial Uses of 206SZZG Bearing
206SZZG Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in demanding environments.

What Makes 206SZZG Bearing a Preferred Choice?
In automotive applications, 206SZZG Bearing fits well in components such as alternators and fans, thanks to its balanced radial load capacity. The ABEC 1 tolerance makes it reliable for everyday use.

Perfect Fit for Automation: 206SZZG Bearing
For automation systems, 206SZZG Bearing works smoothly in robotic arms and conveyor belts. Its shielded seals reduce maintenance needs, making it a practical choice for continuous operation.

Medical vs Industrial: Where 206SZZG Bearing Excels
While 206SZZG Bearing is sturdy enough for industrial gear, its precision also suits medical devices like small lab equipment. The temperature range ensures performance in varied conditions.

How Does 206SZZG Bearing Support High-Speed Operations?
In consumer electronics like printers, 206SZZG Bearing handles high speeds quietly and efficiently. The metric sizing ensures compatibility with a wide range of devices.
