Single Row Deep Groove Ball Bearings 6204

Single Row Deep Groove Ball Bearings 6204

The 6204 is a single-row deep groove ball bearing with a 20mm bore and 47mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 2878 lbf and spins smoothly at speeds up to 15000 RPM.

Its open design simplifies lubrication, while the stainless steel cage ensures durability. The bearing operates reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or small machinery where radial loads are common.

Weighing just 106g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6204
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No CN
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 14 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Required
  • REACH Compliant
  • Temperature Range -30° to 110 °C
  • Dynamic Radial Load 2878 lbf
  • Static Radial Load 1495 lbf
  • Max Speed 15000 rpm
  • Weight 106 g
  • price（$） 1.782
Single Row Deep Groove Ball Bearings 6204 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6204 Bearing

6204 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 2878 lbf, ensuring reliable performance in various applications.

The stainless steel cage maintains ball alignment, reducing friction and wear.
With a maximum speed of 15,000 rpm, it delivers efficient and smooth operation.

6204 Bearing operates in temperatures from -30° to 110°C, suitable for diverse environments.
Its open design simplifies lubrication, helping to extend service life.

Application

Common Applications of 6204 Bearing
The 6204 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its radial load capacity ensures smooth operation. Its open design allows for easy lubrication, extending service life in demanding conditions.

In automotive applications, 6204 Bearing fits well in components like alternators and water pumps, providing reliable performance. The metric sizing makes it a versatile choice for various vehicle models.

For home appliances, 6204 Bearing works efficiently in washing machines and fans, thanks to its balanced load handling. The chrome steel construction offers durability even with frequent use.

Automation systems benefit from 6204 Bearing in robotic arms and conveyor belts, where precision is key. Its stainless steel cage adds resistance to wear in high-speed scenarios.

Medical devices like centrifuges often use 6204 Bearing for its consistent performance. The ABEC-1 tolerance ensures reliable operation in sensitive equipment.
