Single Row Deep Groove Ball Bearings 16100-2Z

Single Row Deep Groove Ball Bearings 16100-2Z

The 16100-2Z is a compact single-row deep groove ball bearing, measuring 10mm by 28mm by 8mm, crafted from durable chrome steel. It handles radial loads up to 1140 lbf and spins smoothly at speeds up to 30,000 RPM.

Shielded on both sides, it keeps grease in and dirt out, making it low-maintenance. The stainless steel cage adds durability, ensuring reliable performance in various conditions.

This bearing works well in temperatures from -30°C to 120°C, suitable for many industrial uses. It’s interchangeable with SKF bearings, offering a cost-effective replacement option.

Ideal for small machinery or electric motors where space is tight but performance is key. Compliant with RoHS and REACH standards, it’s a safe and practical choice.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 16100-2Z
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.007mm to 0
  • Outer Dia 28 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 8 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 1140 lbf
  • Static Radial Load 531 lbf
  • Max Speed 30000 rpm
  • Weight 0.026 kg
  • price（$） 3.915
Single Row Deep Groove Ball Bearings 16100-2Z dimension drawing
Download DWG Download PDF

Features

Why Choose 16100-2Z Bearing for Precision Tasks?

16100-2Z Bearing features a shielded design, protecting against dust and debris while maintaining smooth operation.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

With a dynamic radial load capacity of 1140 lbf, it handles demanding tasks with ease.
The P6 tolerance class guarantees high precision, making it suitable for accurate machinery.

Operating at speeds up to 30,000 rpm, it balances performance and reliability.
Its compact size (10 mm×28 mm×8 mm) allows for easy integration into various systems.

Application

Common Applications of 16100-2Z Bearing
16100-2Z Bearing is widely used in industrial equipment like small electric motors and pumps, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in continuous operation.

In automotive applications, 16100-2Z Bearing fits well in components such as alternators and cooling fans, providing smooth radial load support. Its compact size makes it ideal for space-constrained areas.

For consumer electronics, 16100-2Z Bearing works efficiently in devices like printers and small fans, thanks to its low noise and grease lubrication. The P6 tolerance class ensures reliable performance in precision applications.

Medical devices like lab equipment also benefit from 16100-2Z Bearing’s consistent operation and resistance to wear. The stainless steel cage adds to its longevity in sterile environments.

Automation systems, including small robotic arms, often use 16100-2Z Bearing for its balance of speed and load capacity. The metric sizing ensures compatibility with a variety of machinery designs.
