Single Row Deep Groove Ball Bearings 16004

Single Row Deep Groove Ball Bearings 16004

The 16004 is a single-row deep groove ball bearing with a 20mm bore and 42mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 1416 lbf and operates smoothly at speeds up to 13000 RPM.

Its open design simplifies lubrication, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or small machinery where radial loads are common.

Weighing just 50g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 16004
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No CN
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 42 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 8 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Required
  • REACH Compliant
  • Temperature Range -30° to 110 °C
  • Dynamic Radial Load 1416 lbf
  • Static Radial Load 854 lbf
  • Max Speed 13000 rpm
  • Weight 50 g
  • price（$） 4.176
Single Row Deep Groove Ball Bearings 16004 dimension drawing
Download DWG Download PDF

Features

Why Choose 16004 Bearing for Precision Tasks?

16004 Bearing features a single row deep groove design, ideal for handling radial loads with precision.
Its chrome steel rings and balls provide durability, while the stainless steel cage ensures smooth operation.
With a dynamic radial load capacity of 1416 lbf, it performs reliably in various applications.
The bearing supports speeds up to 13,000 rpm, making it suitable for high-speed machinery.

Application

Common Applications of 16004 Bearing
16004 Bearing is widely used in industrial equipment like small pumps and electric motors, where its radial load capacity ensures smooth operation. The open design simplifies lubrication, making it suitable for moderate-speed applications.

In automotive systems, 16004 Bearing fits well in components such as alternators and cooling fans, providing reliable performance. Its metric sizing and ABEC-1 tolerance make it a versatile choice for various vehicle models.

For home appliances, 16004 Bearing works efficiently in devices like washing machines and fans, thanks to its durable chrome steel construction. The stainless steel cage adds longevity, even with frequent use.

Automation and robotics benefit from 16004 Bearing’s precision in small robotic arms and conveyor systems. Its lightweight design and high-speed capability enhance performance in repetitive tasks.

Medical devices like dental drills often use 16004 Bearing for its consistent radial load handling. The temperature range ensures reliability in both clinical and laboratory environments.
