Single Row Cylindrical Roller Thrust Bearings 812/530 M

Single Row Cylindrical Roller Thrust Bearings 812/530 M

The 812/530 M is a single-row cylindrical roller thrust bearing with a large 530mm bore and 710mm outer diameter, built to handle heavy loads. Made from chrome steel, it supports dynamic radial loads up to 821,250 lbf and operates smoothly at speeds up to 400 RPM.

Its machined brass cage ensures durability and reduces friction, while the precise tolerances provide reliable performance. The bearing works in temperatures from -30°C to 110°C, making it suitable for various industrial environments.

This model is interchangeable with SKF bearings, offering a cost-effective replacement option. Ideal for heavy machinery, mining equipment, or large gearboxes where high thrust loads are common.

Weighing 154kg, it’s a robust choice for demanding applications. Compliant with RoHS and REACH standards for safe and environmentally friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 812/530 M
  • size 530 mm x 710 mm x 140 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 1
  • Bore Dia 530 mm
  • Bore Dia Tolerance -0.050mm to 0
  • Outer Dia 710 mm
  • Outer Dia Tolerance -0.075mm to 0
  • Width 140 mm
  • Height Tolerance -0.60mm to +0.06mm
  • Outside Diameter Shaft Washer 705 mm
  • Bore Diameter Housing Washer 535 mm
  • Height Shaft Washer 40 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 5 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Machined brass cage
  • Dynamic Radial Load 821250 lbf
  • Static Radial Load 4185000 lbf
  • Max Speed 400 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 154 kg
  • Shaft Washer IW_BGD_GEN
  • Housing Washer OW_BGD_GEN
Single Row Cylindrical Roller Thrust Bearings 812/530 M dimension drawing
Download DWG Download PDF

Features

Performance Features of 812/530 M Bearing

812/530 M Bearing is built with chrome steel washers and rollers, offering robust resistance to heavy thrust loads.
Its dynamic radial load capacity reaches 821,250 lbf, making it suitable for demanding industrial applications.

The machined brass cage ensures precise roller alignment, enhancing durability and reducing wear.
With a maximum speed of 400 rpm, it delivers reliable performance under high-stress conditions.

812/530 M Bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its large size (530 mm x 710 mm x 140 mm) is designed for heavy-duty machinery, ensuring long-term reliability.

Application

Industrial Uses of 812/530 M Bearing
812/530 M Bearing is commonly used in heavy machinery, such as large presses and rolling mills, where its cylindrical roller design handles significant thrust loads. The machined brass cage ensures smooth operation even under high-stress conditions.

What Makes 812/530 M Bearing a Preferred Choice?
In wind turbine applications, 812/530 M Bearing’s robust construction and high load capacity make it ideal for supporting rotor shafts. Its chrome steel rollers provide durability in harsh outdoor environments.

Built for Heavy-Duty Use: 812/530 M Bearing
For mining equipment, 812/530 M Bearing excels in conveyor systems and crushers, where its large bore diameter and static load capacity are crucial. The metric sizing ensures compatibility with global machinery standards.

Automotive vs Aerospace: Applications of 812/530 M Bearing
In automotive testing rigs, 812/530 M Bearing handles axial loads during endurance tests, while in aerospace, it supports landing gear mechanisms. Its temperature range suits both ground and high-altitude operations.

Key Fields for 812/530 M Bearing
Marine propulsion systems benefit from 812/530 M Bearing’s resistance to corrosion and high static load capacity. The brass cage reduces friction, enhancing efficiency in long-duration operations.
