24136 CC/W513 Double Row Spherical Roller Bearing

24136 CC/W513 Double Row Spherical Roller Bearing

The 24136 CC/W513 is a double-row spherical roller bearing with a 180mm bore and 300mm outer diameter, built from sturdy chrome steel. It manages combined loads up to 325748 lbf and runs smoothly at speeds up to 1600 RPM.

Its spherical roller design allows for slight misalignment, while the steel cage ensures durability under heavy use. The open construction requires regular lubrication for optimal performance.

This bearing suits high-load applications like industrial gearboxes or mining equipment, where reliability is key. It operates in temperatures from -30°C to 200°C, making it versatile for various environments.

Weighing 33.5kg, it’s a robust choice for demanding machinery. Compliant with RoHS and REACH standards, it’s a safe and reliable option for replacements, interchangeable with SKF models.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24136 CC/W513
  • Brand TFL
  • Interchangeable SKF
  • Size 180 x 300 x 118 mm
  • Bore Dia 180 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 300 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 118 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 203 mm
  • Shoulder/Recess Dia Of Outer Ring 253 mm
  • Width Of Lubrication Groove 11.1 mm
  • Diameter Of Lubrication Hole 6 mm
  • Chamfer Dimension min.3 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 325748 lbf
  • Static Radial Load 485587 lbf
  • Max Speed 1600 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 33.5 kg
  • Price （US$） US$1,061.78

Features

How Does 24136 CC/W513 Bearing Handle Combined Loads?

24136 CC/W513 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined radial and thrust loads.
Its dynamic radial load capacity reaches 325748 lbf, ensuring reliable performance in heavy-duty applications.
The double-row spherical roller design allows for slight misalignment, reducing stress on the bearing.
With a maximum speed of 1600 rpm, it maintains efficiency even under demanding conditions.

What Makes 24136 CC/W513 Bearing Suitable for High-Temperature Applications?

24136 CC/W513 Bearing operates effectively in temperatures ranging from -30° to 200°C.
The chrome steel construction ensures stability and durability in high-heat environments.
Its steel cage maintains roller alignment, preventing premature wear.
Regular lubrication further enhances its performance in extreme conditions.

Engineered for Precision: 24136 CC/W513 Bearing

24136 CC/W513 Bearing features a double-row spherical roller design for precise load distribution.
The cylindrical bore ensures a secure fit, reducing vibration and noise.
Its radial clearance of CN provides optimal performance for various applications.
The lubrication groove and holes facilitate easy maintenance, extending service life.

Why Choose 24136 CC/W513 Bearing for Heavy-Duty Applications?

24136 CC/W513 Bearing’s static radial load capacity of 485587 lbf makes it ideal for heavy loads.
The spherical rollers accommodate misalignment, ensuring smooth operation.
Its robust steel cage keeps rollers in place, minimising wear.
With a width of 118 mm, it offers stability and reliability in demanding setups.

Application

Industrial Uses of 24136 CC/W513 Bearing
The 24136 CC/W513 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles combined loads efficiently. Its chrome steel construction ensures durability in harsh industrial environments.

What Makes 24136 CC/W513 Bearing a Preferred Choice?
In mining equipment, 24136 CC/W513 Bearing excels due to its high dynamic radial load capacity, making it ideal for conveyor systems and pulverisers. The spherical roller design also compensates for minor misalignments.

Built for Heavy-Duty Use: 24136 CC/W513 Bearing
This bearing is a reliable choice for wind turbines, where its open design allows for easy lubrication and maintenance. The wide temperature range ensures performance in varying weather conditions.

Automotive vs Aerospace: Applications of 24136 CC/W513 Bearing
While not typically used in aerospace, 24136 CC/W513 Bearing is found in large commercial vehicles like buses and lorries. Its robust construction supports heavy axles and transmission systems.

Perfect Fit for Automation: 24136 CC/W513 Bearing
In automated production lines, 24136 CC/W513 Bearing provides smooth operation for rotating equipment like rollers and mixers. The steel cage enhances stability during high-speed operations.
