Single Row Angular Contact Ball Bearings (General) 7209 BE-2RZP

Single Row Angular Contact Ball Bearings (General) 7209 BE-2RZP

The 7209 BE-2RZP is a single-row angular contact ball bearing with a 45mm bore and 85mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 8055 lbf and operates smoothly at speeds up to 7500 RPM.

Its sealed design keeps lubrication in and contaminants out, while the nylon cage reduces friction for quieter performance. The 40° contact angle efficiently handles combined radial and axial loads.

This bearing suits applications like pumps or gearboxes where precise angular contact is needed. It works in temperatures from -30°C to 110°C and meets P6 tolerance standards.

Weighing 0.52kg, it’s a robust choice for industrial machinery. Compliant with RoHS and REACH, it’s interchangeable with SKF bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 7209 BE-2RZP
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Sealed
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 85 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 19 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 60.85 mm
  • External Diameter On Inner Ring (Small Side Face) 52.68 mm
  • Chamfer Dimension 1.1 mm
  • Distance Pressure Point (a) 37 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 8055 lbf
  • Static Radial Load 5850 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 7500 rpm
  • Weight 0.52 kg
Single Row Angular Contact Ball Bearings (General) 7209 BE-2RZP dimension drawing
Download DWG Download PDF

Features

Performance Features of 7209 BE-2RZP Bearing

7209 BE-2RZP Bearing is designed with a 40° contact angle, optimising load distribution for angular contact applications.
Its chrome steel construction ensures durability and resistance to wear under dynamic radial loads up to 8055 lbf.

The sealed design and nylon cage provide smooth operation while protecting against contaminants.
With a maximum speed of 7,500 rpm, it balances performance and longevity in various conditions.

7209 BE-2RZP Bearing operates efficiently within a temperature range of -30° to 110°C.
Its P6 tolerance class ensures precision and reliability for demanding industrial applications.

Application

Industrial Uses of 7209 BE-2RZP Bearing
7209 BE-2RZP Bearing is commonly used in machine tools, where its angular contact design handles combined radial and axial loads efficiently. The sealed construction keeps contaminants out, ensuring longer service life in dusty workshops.

In automotive applications, 7209 BE-2RZP Bearing fits well in wheel hubs and transmissions, thanks to its 40° contact angle for stability. The nylon cage reduces friction, making it quieter for passenger vehicles.

For robotics, 7209 BE-2RZP Bearing’s P6 tolerance provides the precision needed for smooth arm movements. Its lubricated design also minimises maintenance in automated production lines.

In household appliances like washing machines, 7209 BE-2RZP Bearing’s chrome steel construction resists wear from frequent use. The metric sizing ensures easy replacement in European-made models.

Medical imaging devices benefit from 7209 BE-2RZP Bearing’s reliable performance under moderate loads. The temperature range suits both sterilisation and operational demands.
