Self Aligning Ball Bearings 2206KEEG15

Self Aligning Ball Bearings 2206KEEG15

The 2206KEEG15 is a self-aligning ball bearing with a 30mm tapered bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3510 lbf and operates smoothly at speeds reaching 7500 RPM.

Its sealed design keeps lubrication intact, while the nylon cage reduces friction for quieter performance. The double-row construction offers stability, even with slight misalignments.

This bearing suits applications like conveyor systems or agricultural machinery, where flexibility and durability are key. It’s interchangeable with SKF models for easy replacements.

Weighing 0.26kg, it’s a compact yet robust choice. Compliant with RoHS and REACH standards, it works in temperatures from -30°C to 110°C.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2206KEEG15
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 20 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 36.7 mm
  • Internal Diameter On Outer Ring 54.06 mm
  • Chamfer Dimension 1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 3510 lbf
  • Static Radial Load 1046 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 7500 rpm
  • Weight 0.26 kg
  • Price（$） 68.66
Self Aligning Ball Bearings 2206KEEG15 dimension drawing
Download DWG Download PDF

Features

Why Choose 2206KEEG15 Bearing for Precision Tasks?

2206KEEG15 Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 3510 lbf makes it suitable for demanding applications.

The sealed construction and nylon cage help maintain smooth operation while reducing contamination risks.
With a maximum speed of 7,500 rpm, it offers both durability and efficiency.

2206KEEG15 Bearing’s tapered bore design simplifies installation and ensures secure fitting.
Its temperature range of -30° to 110 °C allows reliable performance in various environments.

Application

Industrial Uses of 2206KEEG15 Bearing
2206KEEG15 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring long service life in dusty environments.

Where Is 2206KEEG15 Bearing Used?
In automotive applications, 2206KEEG15 Bearing fits well in wheel hubs and transmissions, thanks to its radial load capacity. The tapered bore ensures a secure fit, reducing slippage during operation.

Built for Heavy-Duty Use: 2206KEEG15 Bearing
For heavy machinery like agricultural equipment, 2206KEEG15 Bearing handles high radial loads with ease. The nylon cage reduces friction, making it suitable for continuous operation.

Automotive vs Aerospace: Applications of 2206KEEG15 Bearing
In automotive settings, 2206KEEG15 Bearing supports smooth rotation in drivetrains. For aerospace, its reliability in precision instruments makes it a trusted choice.

Practical Applications of 2206KEEG15 Bearing
2206KEEG15 Bearing works well in electric motors, where its sealed design prevents lubricant leakage. The chrome steel construction ensures durability in high-speed scenarios.
