Self Aligning Ball Bearings SS 2210 2RS

Brand: TFL Bearing Interchangeable: SKF SS 2210 2RS 50 mm × 90 mm × 23 mm Metric Sealed
Part number: SS 2210 2RS
Self Aligning Ball Bearings SS 2210 2RS
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia50 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia90 mm
Outer Dia Tolerance-0.015mm to 0
Width23 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring57.7 mm
Internal Diameter On Outer Ring79.4 mm
Chamfer Dimension1.1 mm
Performance
Dynamic Radial Load5,152 lbf
Static Radial Load1,834 lbf
Temperature Range-30° to 110 °C
Max Speed4,800 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeCylindrical
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceCN
Weight0.57 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The SS 2210 2RS is a self-aligning ball bearing with a 50mm bore and 90mm outer diameter, crafted from robust chrome steel. It handles radial loads up to 5152 lbf and operates smoothly at speeds up to 4800 RPM.

Its double-row design and sealed construction help it stay aligned and protected from dust, while the nylon cage reduces friction. The bearing is pre-lubricated for easy use and works in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 0.57kg, it’s a sturdy yet manageable option. Compliant with RoHS and REACH standards for safe and reliable performance.

Features

Why Choose SS 2210 2RS Bearing for Precision Tasks?

SS 2210 2RS Bearing features a double-row ball design, ensuring smooth radial load distribution.
Its sealed construction keeps contaminants out, maintaining performance in dusty environments.

The chrome steel rings and balls provide durability, while the nylon cage reduces friction.
With a dynamic radial load capacity of 5152 lbf, it handles demanding applications with ease.

SS 2210 2RS Bearing operates quietly, making it suitable for precision instruments.
Its lubricated design ensures long service life with minimal maintenance.

Application

Industrial Uses of SS 2210 2RS Bearing
SS 2210 2RS Bearing is commonly used in conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring longer service life in dusty environments.

What Makes SS 2210 2RS Bearing a Preferred Choice?
In automotive applications like wheel hubs, SS 2210 2RS Bearing handles radial loads smoothly while its nylon cage reduces noise. The metric dimensions make it a versatile fit for various vehicle designs.

Perfect Fit for Automation: SS 2210 2RS Bearing
For robotic arms and automated machinery, SS 2210 2RS Bearing offers reliable performance with its double-row construction. The lubricated design ensures smooth operation even during continuous use.

Medical vs Industrial: Where SS 2210 2RS Bearing Excels
In medical devices like centrifuges, SS 2210 2RS Bearing provides quiet and precise rotation. Its chrome steel rings and sealed design also make it suitable for food processing equipment.
