Self Aligning Ball Bearings 2310KJ

Brand: TFL Bearing Interchangeable: SKF 2310KJ 50 mm × 110 mm × 40 mm Metric Open
Part number: 2310KJ
Self Aligning Ball Bearings 2310KJ
In Stock
US$89.49 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia50 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia110 mm
Outer Dia Tolerance-0.015mm to 0
Width40 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring66 mm
Internal Diameter On Outer Ring92.5 mm
Chamfer Dimension2 mm
Performance
Dynamic Radial Load14,332 lbf
Static Radial Load4,500 lbf
Temperature Range-30° to 110 °C
Max Speed8,500 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Radial ClearanceCN
Weight1.65 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialSteel
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2310KJ is a self-aligning ball bearing with a 50mm tapered bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 14332 lbf and operates smoothly at speeds up to 8500 RPM.

Its double-row design and open construction allow for easy lubrication and alignment adjustments, ideal for misaligned shafts. The steel cage enhances durability, making it reliable for heavy-duty use.

This bearing works well in temperatures from -30°C to 110°C and is interchangeable with SKF models. Perfect for industrial machinery or conveyor systems where alignment flexibility is needed.

Weighing 1.65kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly operation.

Features

Performance Features of 2310KJ Bearing

2310KJ Bearing features a double-row design with chrome steel rings and balls, offering strong radial load capacity.
Its dynamic radial load reaches 14332 lbf, making it suitable for heavy-duty applications.

The tapered bore design ensures easy and secure mounting, reducing installation time.
With a maximum speed of 8,500 rpm, it delivers reliable performance in various conditions.

2310KJ Bearing operates efficiently within a temperature range of -30° to 110°C.
Its steel cage maintains ball alignment, enhancing durability and reducing maintenance needs.

The open seal type allows for easy lubrication, ensuring smooth operation over time.
Weighing 1.65 kg, it balances strength and practicality for industrial use.

Application

Industrial Uses of 2310KJ Bearing
2310KJ Bearing is commonly used in industrial fans and blowers, where its self-aligning feature compensates for minor misalignments. The double-row design ensures stable performance even under heavy radial loads.

In conveyor systems, 2310KJ Bearing helps maintain smooth operation by reducing friction and wear. Its tapered bore allows for secure mounting, making it ideal for high-speed applications.

For agricultural machinery, 2310KJ Bearing’s robust construction handles the demanding conditions of harvesters and tractors. The chrome steel rings provide excellent resistance to wear and corrosion.

Where Is 2310KJ Bearing Used?
You’ll often find 2310KJ Bearing in paper mill equipment, where its ability to handle misalignment is crucial. The open seal design simplifies lubrication and maintenance.

In textile machinery, 2310KJ Bearing supports rotating shafts with precision. Its high dynamic load capacity ensures reliable performance in continuous operation.

Built for Heavy-Duty Use: 2310KJ Bearing
2310KJ Bearing is a solid choice for construction equipment like cranes and excavators. Its steel cage enhances durability under extreme conditions.

The bearing’s wide temperature range makes it suitable for outdoor applications. Whether it’s hot or cold, 2310KJ Bearing performs consistently.

Light-Duty vs Heavy-Duty: Best Uses for 2310KJ Bearing
For light-duty applications like small pumps, 2310KJ Bearing offers smooth rotation with minimal maintenance. Its self-aligning feature is a bonus in compact setups.

In heavy-duty scenarios like mining equipment, 2310KJ Bearing’s high load capacity shines. The tapered bore ensures a tight fit, reducing slippage under stress.
