Self Aligning Ball Bearings 2310 E-2RS1TN9

Self Aligning Ball Bearings 2310 E-2RS1TN9

The 2310 E-2RS1TN9 is a self-aligning ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 9810 lbf and operates smoothly at speeds up to 4000 RPM.

Its double-row design and sealed construction help it stay aligned and protected from dust, making maintenance easier. The nylon cage reduces friction for quieter performance.

This bearing works well in temperatures from -30°C to 110°C, suitable for various industrial settings. It’s interchangeable with SKF bearings, offering a reliable replacement option.

Weighing 1.65kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe choice for machinery requiring consistent radial load support.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2310 E-2RS1TN9
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 40 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 62.9 mm
  • Internal Diameter On Outer Ring 95.2 mm
  • Chamfer Dimension 2 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 9810 lbf
  • Static Radial Load 3150 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4000 rpm
  • Weight 1.65 kg
  • Price（$） 75.6
Self Aligning Ball Bearings 2310 E-2RS1TN9 dimension drawing
Download DWG Download PDF

Features

How Is 2310 E-2RS1TN9 Bearing Engineered for Reliability?

2310 E-2RS1TN9 Bearing features a double-row design with chrome steel rings and balls, ensuring strong radial load capacity.

Its dynamic radial load reaches 9810 lbf, making it suitable for demanding applications.

The sealed construction and nylon cage help maintain smooth operation while reducing contamination risks.

With a maximum speed of 4,000 rpm, it balances durability and performance in various conditions.

Application

Industrial Uses of 2310 E-2RS1TN9 Bearing
2310 E-2RS1TN9 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring long service life in dusty environments.

Where Is 2310 E-2RS1TN9 Bearing Used?
In automotive applications, 2310 E-2RS1TN9 Bearing fits well in suspension systems, handling radial loads smoothly. Its nylon cage reduces noise, making it ideal for passenger vehicles.

Built for Heavy-Duty Use: 2310 E-2RS1TN9 Bearing
For industrial fans, 2310 E-2RS1TN9 Bearing offers reliable performance with its chrome steel construction. The double-row design distributes loads evenly, reducing wear over time.

Automotive vs Industrial: Applications of 2310 E-2RS1TN9 Bearing
In agriculture machinery, 2310 E-2RS1TN9 Bearing withstands harsh conditions, thanks to its sealed and lubricated design. The metric dimensions ensure easy replacement in European equipment.
