Self Aligning Ball Bearings 2302-2RS-TVH-L138

Self Aligning Ball Bearings 2302-2RS-TVH-L138

The 2302-2RS-TVH-L138 is a self-aligning ball bearing with a 15mm bore and 42mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 2678 lbf and operates smoothly at speeds up to 24,000 RPM.

Its double-row design and brass cage provide stability and durability, while the open seal allows for easy lubrication. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like conveyor systems or agricultural machinery where alignment flexibility is needed.

Weighing just 0.12kg, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2302-2RS-TVH-L138
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 15 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 42 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 23.17 mm
  • Internal Diameter On Outer Ring 33.3 mm
  • Chamfer Dimension 1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 2678 lbf
  • Static Radial Load 652 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 24000 rpm
  • Weight 0.12 kg
Self Aligning Ball Bearings 2302-2RS-TVH-L138 dimension drawing
Download DWG Download PDF

Features

Why Choose 2302-2RS-TVH-L138 Bearing for Precision Tasks?

2302-2RS-TVH-L138 Bearing features a double-row design, ensuring smooth radial load distribution for precise applications.
Its chrome steel rings and balls provide durability, while the brass cage maintains alignment under high speeds.

With a dynamic radial load capacity of 2678 lbf, it handles demanding conditions without compromising performance.
The bearing operates efficiently at speeds up to 24,000 rpm, making it suitable for high-speed machinery.

2302-2RS-TVH-L138 Bearing’s lubricated design reduces friction, ensuring long-lasting operation.
Its temperature range of -30° to 110°C allows reliable use in various environments.

Application

Industrial Uses of 2302-2RS-TVH-L138 Bearing
2302-2RS-TVH-L138 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The double-row design ensures reliable performance even under heavy radial loads.

In automotive applications, 2302-2RS-TVH-L138 Bearing fits well in gearboxes and wheel hubs, providing smooth rotation. Its brass cage offers good wear resistance, making it suitable for high-speed operations.

For automation equipment, 2302-2RS-TVH-L138 Bearing is ideal for robotic arms due to its precise alignment capabilities. The lubricated design reduces maintenance needs, ensuring long service life.

In household appliances like washing machines, 2302-2RS-TVH-L138 Bearing handles vibrations effectively. The chrome steel construction ensures durability in daily use.

Medical devices such as centrifuges benefit from 2302-2RS-TVH-L138 Bearing’s quiet operation. The CN radial clearance provides consistent performance in sensitive applications.
