Self Aligning Ball Bearings 2211E-K 2RS

Brand: TFL Bearing Interchangeable: SKF 2211E-K 2RS 55 mm × 100 mm × 25 mm Metric Sealed
Part number: 2211E-K 2RS
Self Aligning Ball Bearings 2211E-K 2RS
In Stock
US$143.99 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia55 mm
Bore Dia Tolerance-0.015mm to 0
Outer Dia100 mm
Outer Dia Tolerance-0.015mm to 0
Width25 mm
Width Tolerance-0.15mm to 0
External Diameter On Inner Ring65.9 mm
Internal Diameter On Outer Ring88.5 mm
Chamfer Dimension1.5 mm
Performance
Dynamic Radial Load6,210 lbf
Static Radial Load2,385 lbf
Temperature Range-30° to 110 °C
Max Speed4,300 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceCN
Weight0.79 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2211E-K 2RS is a self-aligning ball bearing with a 55mm tapered bore and 100mm outer diameter, designed for radial loads. Made from chrome steel, it handles up to 6210 lbf and runs smoothly at speeds up to 4300 RPM.

Its double-row design and sealed construction help it stay aligned and protected from dust, while the nylon cage reduces noise. The bearing comes pre-lubricated for easy installation.

This model works well in temperatures from -30°C to 110°C and is interchangeable with SKF bearings. Ideal for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 0.79kg, it’s a sturdy choice for industrial use. Compliant with RoHS and REACH standards for safety and environmental friendliness.

Features

Why Choose 2211E-K 2RS Bearing for Precision Tasks?

2211E-K 2RS Bearing features a double-row design with chrome steel rings and balls, ensuring smooth radial load handling.
Its dynamic radial load capacity of 6210 lbf makes it suitable for demanding applications.

The sealed construction and nylon cage reduce contamination risks, enhancing durability.
With a maximum speed of 4,300 rpm, it balances performance and longevity.

2211E-K 2RS Bearing operates efficiently in temperatures from -30° to 110°C.
Its tapered bore design simplifies installation and improves alignment accuracy.

Application

Industrial Uses of 2211E-K 2RS Bearing
2211E-K 2RS Bearing is commonly used in conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring longer service life in dusty environments.

In automotive applications, 2211E-K 2RS Bearing fits well in wheel hubs and transmissions, thanks to its radial load capacity. The tapered bore provides a secure fit, reducing slippage under heavy loads.

For robotics, 2211E-K 2RS Bearing offers smooth movement in joint mechanisms, with its double-row construction handling multi-directional forces. The nylon cage reduces friction, making it ideal for precision tasks.

In household appliances like washing machines, 2211E-K 2RS Bearing’s durability and sealed design prevent water damage. Its metric sizing ensures compatibility with a variety of European-made appliances.
