Self Aligning Ball Bearings 2210

Self Aligning Ball Bearings 2210

The 2210 is a self-aligning ball bearing with a 50mm bore and 90mm outer diameter, designed for radial loads. Its compact 23mm width and double-row construction make it sturdy yet space-efficient.

Made from chrome steel with a nylon cage, it handles dynamic radial loads up to 5152 lbf and spins smoothly at 4800 RPM. The sealed design keeps lubrication in and contaminants out.

This bearing adjusts to minor misalignments, reducing wear in uneven setups. It’s pre-lubricated and works in temperatures from -30°C to 110°C.

Ideal for machinery like conveyor belts or agricultural equipment where alignment isn’t perfect. Weighing 0.57kg, it’s robust for its size and complies with RoHS and REACH standards.

Interchangeable with SKF bearings, it’s a practical choice for replacements or upgrades.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2210
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 57.7 mm
  • Internal Diameter On Outer Ring 79.4 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 5152 lbf
  • Static Radial Load 1834 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4800 rpm
  • Weight 0.57 kg
Self Aligning Ball Bearings 2210 dimension drawing
Download DWG Download PDF

Features

Performance Features of 2210 Bearing

2210 Bearing is designed with double-row chrome steel balls, offering excellent radial load capacity up to 5152 lbf.
Its sealed construction prevents contamination, ensuring smooth operation in various environments.
The nylon cage reduces friction and noise, making it suitable for precision applications.
With a maximum speed of 4,800 rpm, it balances performance and durability.

Application

Industrial Uses of 2210 Bearing
The 2210 Bearing is commonly used in industrial machinery where misalignment compensation is needed, such as conveyor systems and textile equipment. Its double-row design helps maintain smooth operation even under radial loads.

What Makes 2210 Bearing a Preferred Choice?
In automotive applications, 2210 Bearing works well in gearboxes and wheel hubs due to its sealed construction, which keeps contaminants out. The nylon cage reduces friction, making it suitable for moderate-speed operations.

Perfect Fit for Automation: 2210 Bearing
For robotics and automated systems, 2210 Bearing’s self-aligning feature ensures reliable performance in articulated arms. The chrome steel rings provide durability in repetitive motion scenarios.

Medical vs Industrial: Where 2210 Bearing Excels
In medical devices like centrifuges, 2210 Bearing offers quiet and stable rotation. Its lubricated design ensures consistent performance in both industrial and precision medical environments.
