Self Aligning Ball Bearings 2210 EKTN9/C3

Self Aligning Ball Bearings 2210 EKTN9/C3

The 2210 EKTN9/C3 is a self-aligning ball bearing with a 50mm bore and 90mm outer diameter, crafted from sturdy chrome steel. Its double-row design helps manage radial loads up to 7605 lbf, while allowing smooth rotation at speeds up to 9500 RPM.

The open seal type and C3 radial clearance make it suitable for applications where slight misalignment or thermal expansion occurs. The nylon cage reduces friction and noise, enhancing durability.

This bearing is pre-lubricated and operates efficiently in temperatures from -30°C to 110°C. It’s interchangeable with SKF models, offering a reliable option for replacements.

Weighing 0.6kg, it’s a practical choice for industrial machinery, pumps, or fans where alignment flexibility is needed. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2210 EKTN9/C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 61.47 mm
  • Internal Diameter On Outer Ring 80.2 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 7605 lbf
  • Static Radial Load 2520 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 9500 rpm
  • Weight 0.6 kg
  • Price（$） 54.7
Self Aligning Ball Bearings 2210 EKTN9/C3 dimension drawing
Download DWG Download PDF

Features

Why Choose 2210 EKTN9/C3 Bearing for Precision Tasks?

2210 EKTN9/C3 Bearing features a double-row ball design with chrome steel rings and balls, ensuring high radial load capacity.
Its dynamic radial load reaches 7605 lbf, making it suitable for demanding applications.

The nylon cage maintains ball alignment, reducing friction and extending service life.
With a maximum speed of 9,500 rpm, it offers both durability and efficiency.

2210 EKTN9/C3 Bearing operates smoothly in temperatures from -30° to 110°C, adapting to various environments.
Its C3 radial clearance provides optimal performance under different load conditions.

The open seal design allows for easy lubrication, ensuring consistent performance.
This bearing is ideal for applications requiring precision and reliability.

Application

Industrial Uses of 2210 EKTN9/C3 Bearing
The 2210 EKTN9/C3 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. Its double-row design ensures reliable performance under radial loads in heavy-duty environments.

Where Is 2210 EKTN9/C3 Bearing Used?
You’ll often find 2210 EKTN9/C3 Bearing in agricultural machinery, such as tractors and harvesters. Its tapered bore provides a secure fit, reducing slippage during high-torque operations.

Built for Heavy-Duty Use: 2210 EKTN9/C3 Bearing
The 2210 EKTN9/C3 Bearing handles radial loads effortlessly in industrial fans and blowers. Its nylon cage reduces friction, making it suitable for continuous operation.

Automotive vs Aerospace: Applications of 2210 EKTN9/C3 Bearing
In automotive applications, 2210 EKTN9/C3 Bearing supports gearboxes and drivetrains. For aerospace, its precision and durability make it ideal for auxiliary equipment.

Perfect Fit for Automation: 2210 EKTN9/C3 Bearing
The 2210 EKTN9/C3 Bearing works well in robotic arms, where smooth rotation is essential. Its chrome steel construction ensures long-lasting performance in repetitive motions.
