Self Aligning Ball Bearings 2210 E-2RS1TN9/C3

Self Aligning Ball Bearings 2210 E-2RS1TN9/C3

The 2210 E-2RS1TN9/C3 is a self-aligning ball bearing with a 50mm bore and 90mm outer diameter, crafted from sturdy chrome steel. Its double-row design and sealed construction help it handle radial loads up to 5152 lbf while running smoothly at 4800 RPM.

The nylon cage reduces friction, and the C3 radial clearance allows for thermal expansion, making it reliable in varying temperatures (-30°C to 110°C). Pre-lubricated for easy installation, it’s ready to use straight out of the box.

This bearing is interchangeable with SKF models, ideal for machinery where misalignment or heavy radial loads are expected, like conveyor systems or agricultural equipment. Weighing 0.57kg, it’s a robust yet manageable choice for industrial applications.

Compliant with RoHS and REACH standards, it’s a safe and durable option for long-term use. The sealed design keeps contaminants out, extending its service life.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2210 E-2RS1TN9/C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 57.7 mm
  • Internal Diameter On Outer Ring 79.4 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 5152 lbf
  • Static Radial Load 1834 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4800 rpm
  • Weight 0.57 kg
Self Aligning Ball Bearings 2210 E-2RS1TN9/C3 dimension drawing
Download DWG Download PDF

Features

How Is 2210 E-2RS1TN9/C3 Bearing Engineered for Reliability?

2210 E-2RS1TN9/C3 Bearing features a double-row design with chrome steel rings and balls, ensuring strong radial load capacity.
Its dynamic radial load rating of 5152 lbf makes it suitable for demanding applications.

The sealed construction and nylon cage help maintain smooth operation by keeping contaminants out.
With a maximum speed of 4,800 rpm, it balances performance and durability.

2210 E-2RS1TN9/C3 Bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its C3 radial clearance ensures reliable performance under varying thermal conditions.

Application

Common Applications of 2210 E-2RS1TN9/C3 Bearing
2210 E-2RS1TN9/C3 Bearing is widely used in industrial machinery, especially in conveyor systems and pumps, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring long service life in dusty environments.

In automotive applications, 2210 E-2RS1TN9/C3 Bearing is often found in wheel hubs and transmissions, providing smooth rotation under radial loads. Its nylon cage reduces noise, making it ideal for passenger vehicles.

For automation equipment, 2210 E-2RS1TN9/C3 Bearing supports robotic arms and assembly lines, where precision and reliability are key. The C3 clearance allows for thermal expansion, maintaining performance in varying temperatures.

In household appliances like washing machines, 2210 E-2RS1TN9/C3 Bearing ensures quiet and efficient operation. The lubricated design minimizes maintenance, perfect for high-use domestic settings.
