Self Aligning Ball Bearings 2210-2RS-TVH-C3

Self Aligning Ball Bearings 2210-2RS-TVH-C3

The 2210-2RS-TVH-C3 is a self-aligning ball bearing with a 50mm bore and 90mm outer diameter, designed for radial loads. Its compact 23mm width makes it suitable for tight spaces, while the chrome steel construction ensures durability.

This double-row bearing handles radial loads up to 5152 lbf and operates smoothly at speeds up to 4800 RPM. The sealed design keeps lubrication in and contaminants out, reducing maintenance needs.

Its self-aligning feature compensates for minor misalignments, making installation easier. The nylon cage reduces friction and noise, ideal for quieter operations.

Perfect for applications like conveyor systems or agricultural machinery, where misalignment and radial loads are common. Compliant with RoHS and REACH standards, it weighs just 0.57kg for easy handling.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2210-2RS-TVH-C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 57.7 mm
  • Internal Diameter On Outer Ring 79.4 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 5152 lbf
  • Static Radial Load 1834 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4800 rpm
  • Weight 0.57 kg
Self Aligning Ball Bearings 2210-2RS-TVH-C3 dimension drawing
Download DWG Download PDF

Features

How Does 2210-2RS-TVH-C3 Bearing Reduce Friction?

2210-2RS-TVH-C3 Bearing features a double-row design with chrome steel balls, ensuring smooth radial load distribution.
The nylon cage minimises friction, enhancing efficiency and reducing wear over time.

Its sealed construction keeps lubrication intact, maintaining performance in various conditions.
With a dynamic radial load capacity of 5152 lbf, it handles demanding applications reliably.

The C3 radial clearance allows for thermal expansion, ensuring consistent operation.
This makes 2210-2RS-TVH-C3 Bearing suitable for high-speed use up to 4,800 rpm.

Application

Industrial Uses of 2210-2RS-TVH-C3 Bearing
2210-2RS-TVH-C3 Bearing is commonly used in industrial machinery like pumps and fans, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring longer service life in dusty environments.

What Makes 2210-2RS-TVH-C3 Bearing a Preferred Choice?
In automotive applications, 2210-2RS-TVH-C3 Bearing works well in wheel hubs and transmissions, thanks to its radial load capacity and durability. The nylon cage reduces friction, making it quieter and more efficient.

Perfect Fit for Automation: 2210-2RS-TVH-C3 Bearing
For robotics and automation, 2210-2RS-TVH-C3 Bearing offers smooth operation in robotic arms and conveyor systems. Its C3 clearance allows for thermal expansion, ideal for high-speed operations.

Medical vs Industrial: Where 2210-2RS-TVH-C3 Bearing Excels
In medical devices like MRI machines, 2210-2RS-TVH-C3 Bearing provides reliable performance with minimal maintenance. Meanwhile, in industrial settings, it handles heavy radial loads in gearboxes and compressors.

Where to Use 2210-2RS-TVH-C3 Bearing
2210-2RS-TVH-C3 Bearing is great for household appliances like washing machines, where its sealed design prevents grease leakage. The chrome steel construction ensures it can handle daily wear and tear.
