Self Aligning Ball Bearings 2208-2RSTN

Brand: TFL Bearing Interchangeable: SKF 2208-2RSTN 40 mm × 80 mm × 23 mm Metric Sealed
Part number: 2208-2RSTN
Self Aligning Ball Bearings 2208-2RSTN
In Stock
US$95.68 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia40 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia80 mm
Outer Dia Tolerance-0.013mm to 0
Width23 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring49 mm
Internal Diameter On Outer Ring69.8 mm
Chamfer Dimension1.1 mm
Performance
Dynamic Radial Load4,478 lbf
Static Radial Load1,564 lbf
Temperature Range-30° to 110 °C
Max Speed5,600 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeCylindrical
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceCN
Weight0.5 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2208-2RSTN is a self-aligning ball bearing with a 40mm bore and 80mm outer diameter, measuring 23mm wide. Made from chrome steel, it’s built to handle radial loads up to 4478 lbf and speeds of 5600 RPM.

Its double-row design and sealed construction help it stay aligned and protected from dust, while the nylon cage reduces friction. The bearing comes pre-lubricated for easy installation.

This model works in temperatures from -30°C to 110°C and is interchangeable with SKF bearings. Ideal for machinery where misalignment or heavy radial loads are expected.

Weighing 0.5kg, it’s a sturdy yet manageable choice for industrial applications. Compliant with RoHS and REACH standards.

Features

Why Choose 2208-2RSTN Bearing for Precision Tasks?

2208-2RSTN Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 4478 lbf makes it suitable for high-performance applications.

The sealed construction and nylon cage provide smooth operation while reducing maintenance needs.
With a maximum speed of 5,600 rpm, it balances efficiency and durability.

2208-2RSTN Bearing operates in temperatures from -30° to 110°C, adapting to various working conditions.
Its compact size (40 mm×80 mm×23 mm) allows for easy integration into different systems.

Application

Industrial Uses of 2208-2RSTN Bearing
2208-2RSTN Bearing works well in conveyor systems, where its self-aligning feature helps handle minor shaft misalignments. The sealed design keeps contaminants out, making it suitable for dusty factory environments.

Where Is 2208-2RSTN Bearing Used?
You’ll often find 2208-2RSTN Bearing in agricultural machinery, like harvesters, where its double-row construction handles heavy radial loads. The nylon cage reduces friction, ensuring smoother operation over long periods.

Built for Heavy-Duty Use: 2208-2RSTN Bearing
2208-2RSTN Bearing is a solid choice for industrial fans, thanks to its chrome steel rings and lubricated design. It handles high speeds well, making it reliable for continuous operation.

Automotive vs Industrial: Applications of 2208-2RSTN Bearing
In automotive applications, 2208-2RSTN Bearing supports auxiliary units like alternators, where its sealed design prevents grease leakage. For industrial pumps, its radial load capacity ensures consistent performance under pressure.

Perfect Fit for Automation: 2208-2RSTN Bearing
2208-2RSTN Bearing is handy in packaging machines, where its self-aligning capability compensates for slight misalignments. The metric sizing makes it easy to integrate into European-designed equipment.
