Self Aligning Ball Bearings 2206EKTN

Self Aligning Ball Bearings 2206EKTN

The 2206EKTN is a self-aligning ball bearing with a 30mm tapered bore and 62mm outer diameter, built to handle radial loads. Its compact 20mm width makes it a space-saving choice for tight installations.

Made from chrome steel with a nylon cage, it offers smooth rotation and durability. The sealed design keeps lubrication in and contaminants out, reducing maintenance needs.

With a dynamic radial load capacity of 3510 lbf, it’s suited for moderate to heavy loads. It spins efficiently at speeds up to 7500 RPM and operates in temperatures from -30°C to 110°C.

Ideal for applications like conveyor systems or agricultural machinery where misalignment might occur. Compliant with RoHS and REACH standards, it’s a reliable and safe option for various industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2206EKTN
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 20 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 36.7 mm
  • Internal Diameter On Outer Ring 54.06 mm
  • Chamfer Dimension 1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 3510 lbf
  • Static Radial Load 1046 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 7500 rpm
  • Weight 0.26 kg
  • Price（$） 25.74
Self Aligning Ball Bearings 2206EKTN dimension drawing
Download DWG Download PDF

Features

Why Choose 2206EKTN Bearing for Precision Tasks?

2206EKTN Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 3510 lbf makes it suitable for high-performance applications.

The sealed construction and nylon cage reduce friction, enhancing smooth operation and longevity.
With a maximum speed of 7,500 rpm, it delivers reliable performance in various conditions.

2206EKTN Bearing operates efficiently within a temperature range of -30° to 110°C, adapting to diverse environments.
Its tapered bore design simplifies installation, saving time and effort during setup.

Application

Industrial Uses of 2206EKTN Bearing
2206EKTN Bearing is commonly used in industrial machinery, especially in conveyor systems and pumps, where its self-aligning feature compensates for minor misalignments. The sealed design helps keep contaminants out, extending the bearing’s lifespan in dusty environments.

In automotive applications, 2206EKTN Bearing fits well in steering columns and drivetrain components, thanks to its radial load capacity and tapered bore. The nylon cage reduces noise, making it suitable for smoother rides.

For automation equipment, 2206EKTN Bearing’s double-row construction provides stability in robotic arms and assembly lines. Its lubricated design ensures consistent performance even during prolonged use.

In household appliances like washing machines, 2206EKTN Bearing’s durability and sealed construction prevent water damage, ensuring reliable operation over time. The chrome steel rings add to its resistance against wear.
