Self Aligning Ball Bearings 2201-2RSTN

Self Aligning Ball Bearings 2201-2RSTN

The 2201-2RSTN is a self-aligning ball bearing with a 12mm bore and 32mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 1404 lbf and operates smoothly at speeds up to 16000 RPM.

Its double-row design and sealed construction help maintain alignment and protect against contaminants, while the nylon cage reduces friction. The bearing comes pre-lubricated for easy installation.

Suitable for applications with minor misalignments, such as conveyor systems or agricultural machinery. It works in temperatures from -30°C to 110°C.

Weighing just 0.053kg, it’s lightweight and durable. Compliant with RoHS and REACH standards, and interchangeable with SKF bearings for hassle-free replacements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2201-2RSTN
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 32 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 14 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 15.5 mm
  • Internal Diameter On Outer Ring 27.34 mm
  • Chamfer Dimension 0.6 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 1404 lbf
  • Static Radial Load 322 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 16000 rpm
  • Weight 0.053 kg
  • Price（$） 54.29
Self Aligning Ball Bearings 2201-2RSTN dimension drawing
Download DWG Download PDF

Features

Why Choose 2201-2RSTN Bearing for Precision Tasks?

2201-2RSTN Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 1404 lbf makes it suitable for high-performance applications.
The sealed construction and nylon cage reduce friction and protect against contaminants.
With a maximum speed of 16,000 rpm, it delivers smooth and efficient operation.

Application

Common Applications of 2201-2RSTN Bearing
In industrial settings, 2201-2RSTN Bearing is commonly used in conveyor systems and fans, where its self-aligning feature compensates for minor misalignments. The sealed design helps keep contaminants out, extending its service life in dusty environments.

Where Is 2201-2RSTN Bearing Used?
You’ll often find 2201-2RSTN Bearing in automotive applications like electric motors and pumps, thanks to its ability to handle radial loads smoothly. The nylon cage reduces friction, making it a quiet and efficient choice for vehicle components.

Built for Heavy-Duty Use: 2201-2RSTN Bearing
In robotics and automation, 2201-2RSTN Bearing is ideal for mechanical arms and 3D printers, where precision and reliability are key. Its double-row construction provides added stability, ensuring consistent performance even under continuous use.

Medical vs Industrial: Where 2201-2RSTN Bearing Excels
For medical devices like lab equipment, 2201-2RSTN Bearing offers reliable performance with minimal maintenance. In industrial machinery, its chrome steel rings and lubricated design make it a durable option for high-speed operations.

Perfect Fit for Automation: 2201-2RSTN Bearing
In home appliances like washing machines, 2201-2RSTN Bearing ensures smooth operation with its sealed and lubricated design. The metric sizing makes it easy to integrate into various European and Asian appliance models.
