Single Row Deep Groove Ball Bearings 6206-2Z/WT

The 6206-2Z/WT is a single-row deep groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. Its shielded design keeps dirt out while maintaining smooth operation.

This model handles radial loads up to 4384 lbf and spins efficiently at speeds reaching 11000 RPM. The chrome steel cage provides durability, and it performs well in temperatures from -30°C to 120°C.

With ABEC 1 precision and ISO P0 tolerance, it offers reliable performance for everyday use. The shielded seals help extend bearing life by preventing contamination.

Ideal for electric motors, pumps, or gearboxes where consistent radial load support is needed. Weighing 199g, it’s a lightweight yet robust solution for various industrial applications. Compliant with RoHS and REACH standards.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6206-2Z/WT
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Shielded
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No CN
Bore Dia 30 mm
Bore Dia Tolerance -0.01mm to 0
Outer Dia 62 mm
Outer Dia Tolerance -0.013mm to 0
Width 16 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 4384 lbf
Static Radial Load 254 lbf
Max Speed 11000 rpm
Weight 199 g

Single Row Deep Groove Ball Bearings 6206-2Z/WT dimension drawing

Download DWG Download PDF

Features

Performance Features of 6206-2Z/WT Bearing

6206-2Z/WT Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 4384 lbf, ensuring reliable performance in various applications.

The shielded design of 6206-2Z/WT Bearing protects against dust and debris, enhancing durability.
With a maximum speed of 11,000 rpm, it balances efficiency and longevity.

6206-2Z/WT Bearing operates smoothly in temperatures ranging from -30°C to 120°C.
Its chrome steel cage ensures stable ball alignment, reducing wear over time.

The ABEC 1 tolerance class of 6206-2Z/WT Bearing provides consistent precision.
This makes it suitable for applications where reliable radial load support is needed.

Application

Industrial Uses of 6206-2Z/WT Bearing
6206-2Z/WT Bearing is commonly used in conveyor systems, where its shielded design protects against dust and debris. The chrome steel construction ensures durability in demanding industrial environments.

What Makes 6206-2Z/WT Bearing a Preferred Choice?
In automotive applications like electric motors, 6206-2Z/WT Bearing offers reliable radial load support. Its ABEC 1 tolerance makes it suitable for standard precision requirements.

Perfect Fit for Automation: 6206-2Z/WT Bearing
This bearing works well in robotic arms, providing smooth motion with its deep groove design. The temperature range of -30° to 120°C allows for versatile use in various climates.

Light-Duty vs Heavy-Duty: Best Uses for 6206-2Z/WT Bearing
For light-duty tasks like office printers, 6206-2Z/WT Bearing ensures quiet operation. In heavier applications like pumps, it handles radial loads efficiently.

Where Is 6206-2Z/WT Bearing Used?
You’ll find 6206-2Z/WT Bearing in household appliances like washing machines, where its shielded design keeps out moisture. The metric sizing fits most European-made devices.
