Single Row Deep Groove Ball Bearings 6013/DT-2RS1

Single Row Deep Groove Ball Bearings 6013/DT-2RS1

The 6013/DT-2RS1 is a single-row deep groove ball bearing with a 65mm bore and 100mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 6857 lbf and operates smoothly at speeds up to 6700 RPM.

Sealed on both sides, this bearing keeps out dust and moisture, ensuring reliable performance in various conditions. The chrome steel cage adds durability, making it a long-lasting choice.

With a compact width of 18mm, it fits neatly into tight spaces while handling significant loads. Its temperature range of -30°C to 120°C suits diverse environments.

Ideal for applications like electric motors or pumps where radial loads and contamination resistance are key. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6013/DT-2RS1
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 18 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6857 lbf
  • Static Radial Load 5665 lbf
  • Max Speed 6700 rpm
  • Weight 430 g
Single Row Deep Groove Ball Bearings 6013/DT-2RS1 dimension drawing
Download DWG Download PDF

Features

Why Choose 6013/DT-2RS1 Bearing for Precision Tasks?

6013/DT-2RS1 Bearing features a sealed design, protecting it from dust and moisture for consistent performance.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

With a dynamic radial load capacity of 6857 lbf, it handles demanding conditions reliably.
The bearing operates smoothly up to 6,700 rpm, making it suitable for high-speed applications.

Its temperature range of -30°C to 120°C allows for use in various environments.
The sealed design also reduces maintenance needs, saving time and effort.

Application

Common Applications of 6013/DT-2RS1 Bearing
6013/DT-2RS1 Bearing is widely used in industrial machinery, such as pumps and electric motors, where its sealed design helps keep out contaminants. The chrome steel construction ensures durability even in demanding environments.

In automotive applications, 6013/DT-2RS1 Bearing is often found in wheel hubs and transmissions, providing reliable performance under radial loads. Its metric sizing makes it a versatile choice for various vehicle models.

For automation systems, 6013/DT-2RS1 Bearing supports smooth operation in robotic arms and conveyor belts. The sealed design reduces maintenance needs, making it ideal for high-use scenarios.

In household appliances like washing machines, 6013/DT-2RS1 Bearing offers quiet and efficient performance. Its robust design ensures long-lasting reliability in everyday use.
